TAPs for PortOM_OD Alarm Group
TAP-306: Clear 'OMS LOS: 0GHz and 100GHz offset at OD
(0GHz offset)'
....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
365-575-783R1.1
Issue 1, June 2002
For the context of this alarm, the Optical Multiplex Section (OMS) is
the line between the Optical Preamplifier (OA) OUT connector and
IN 0/100 GHz connector of the Optical Demultiplexer Unit (OD 100).
This condition indicates that the OD (0 GHz offset) has detected a
total loss of input signal.
............................................................................................................................................................
Examine the NE Alarm List
1
............................................................................................................................................................
Remove the appropriate shelf cover. All connections can be accessed
2
from the front. For details, go to
Cover" (7-17).
............................................................................................................................................................
CAUTION
SERVICE AFFECTING - This step could result in service
interruption.
Notify the person responsible for services supported by this optical
3
multiplex section to ensure that it is not utilized until the problem has
been resolved.
............................................................................................................................................................
Visually inspect the incoming signal cable between the OA OUT_SIG
4
port and the IN_0/100 port and correct any problems found. For
details, go to "DLP-609: Inspect Optical Fiber(s)"
..........................................................................................................................................................
Did the visual inspection result in correcting any problems?
5
IF...
YES
NO
Lucent Technologies - Proprietary
See notice on first page
.
"DLP-607: Remove/Install Front
THEN...
Go to Step 17.
Continue with Step
Trouble Clearing Tasks
(7-31).
6.
