DLP-607: Remove/Install Front Cover
Install a shelf cover
....................................................................................................................................................................................................................................
365-575-783R1.1
Issue 1, June 2002
To re-install a cover, reverse the procedure to
cover" (7-17):
............................................................................................................................................................
Replace the cover, inserting the bottom corners of the cover into the
1
two hinge brackets, and pressing the top of the cover into place, flush
with the bay.
............................................................................................................................................................
Rotate the open latch handles 90 degrees clockwise to close the
2
latches.
............................................................................................................................................................
Push on the raised edge of each latch handle to close it, so it is flush
3
with the latch mechanism.
............................................................................................................................................................
Rotate the locking screws 90 degrees clockwise to secure the latch
4
handles.
E S
N D O F T E P S
.........................................................................................................................................................................................................................................................
