DLP-610: Replace Power Line Filter
....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
7 - 3 2
Follow the procedure below to replace a power line filter. There are
two power line filters in each double-shelf, located in slots 16A and
16C of shelves 1 and 3.
............................................................................................................................................................
1 Identify the correct power line filter to be removed.
............................................................................................................................................................
Set the circuit breaker on the replacement filter to the off position.
2
............................................................................................................................................................
Remove the shelf cover. For details refer to
3
Remove/Install Front Cover"
............................................................................................................................................................
If equipped, remove the interconnect panel cover on the power filter
4
shelf. For details, refer to
(7-17).
............................................................................................................................................................
Unplug the filters power cable by depressing both tabs at the same
5
time and pulling the connector from the filters socket.
............................................................................................................................................................
Loosen the screw holding the filter to its holding bracket using a
6
flat-bladed screwdriver.
............................................................................................................................................................
Remove the defective filter by sliding it out towards the front of the
7
shelf.
............................................................................................................................................................
WARNING
When inserting a power filter into the shelf, ensure that the
plastic power connector on the filter clears the power filters
screw bracket. This will prevent damage to the plastic power
connector.
Lucent Technologies - Proprietary
See notice on first page
"DLP-607:
(7-17).
"DLP-607: Remove/Install Front Cover"
