Goodrive20-UL Series VFD
Function
Name
code

P13 group SM control

Function
Name
code
Frequency
P13.09 switching
point
Braking
P13.13 current of
short circuit
Braking
retention
P13.14 time of
starting
short circuit
Braking
retention
P13.15 time of
stopping
short circuit

P14 group Serial communication

Function
Name
code
Local
P14.00 communicati
on address
Description
0: Disable
1: Enable
Tens place: Second ACC/DEC time
selection
0: Disable
1: Enable. When the running frequency
exceeds P08.36, ACC/DEC time is switched
to the second ACC/DEC time.
Description
0.00–630.00
After the VFD starts, when P01.00=0, set
P13.14 to non-zero value and begin short
circuit braking.
After the VFD stops, when the operation
frequency is less than P01.09, set P13.15 to
non-zero value and begin stopping
short-circuit braking and then DC braking.
Setting range of P13.13: 0.0–150.0%
(relative to the percentage of rated current of
the VFD)
Setting range of P13.14: 0.00–50.00s
Description
Setting range: 1–247
When the master is writing the frame, the
communication address of the slave is set to
0. The broadcast address is the
communication address. All slaves on the
Modbus fieldbus can receive the frame, but
the salve doesn't answer.
-94-
Function parameters
Default Modify
Default Modify
○
50.00
○
0.0%
○
0.00s
○
0.00s
Default Modify
○
1
