Honda BF135A Manual page 19

• STERN BRACKET
7/8-14 UNF self-locking nut
25 x 2.0 mm self-locking nut
10 mm self-locking nut
• POWER TRIM/TILT ASSEMBLY
Cylinder cap comp.
Rod guide comp.
Manual valve
Socket bolt A/B
Power tilt motor assembly bolt
Power tilt motor assembly code holder screw
Oil tank bolt
Oil tank cap
• FRAME/ELECTRICAL
Grease fitting
Neutral switch nut
Starter motor B terminal washer-nut
Alternator B terminal washer-nut
Alternator fuse box B terminal washer-nut
Alternator fuse box bolt
Fuse box bracket bolt
PGM-FI main relay bolt
ECM bracket bolt
L./R. engine under cover screw
Starter motor bolt
• Use the standard torque values for the bolts, nuts and screws that are not listed in this table.
STANDARD TORQUE VALUES
Screw
Bolt and nut
Flange bolt and nut
• CT bolt: Self-tapping bolt
• SH bolt: Small head bolt
2-9
Item
Item
Thread dia. (mm)
and pitch (length)
7/8-14 UNF
M25 x 2.0
M10 x 1.25
M14 x 1.5
1/4-20 UNF
M4 screw
M6 x 1.0
M20 x 1.0
M8 x 1.25
M6 x 1.0
M6 x 1.0
M6 x 1.0
M6 x 1.0
M6 x 1.0
M6 x 1.0
M6 screw
M10 x 1.25
Thread dia. (mm)
and pitch (length)
5 mm
6 mm
5 mm
6 mm
8 mm
10 mm
12 mm
6 mm (SH bolt)
6 mm (CT bolt)
6 mm
8 mm
10 mm
Torque value
N . m kgf . m
34 3.5
34 3.5
34 3.5
162 16.5
78 8.0
3.5 0.35
8.5 0.85
5 0.5
1.4 0.14
5 0.5
2.5 0.25
3 0.3
2.5 0.25
11 1.1
8 0.8
8 0.8
5 0.5
5 0.5
5 0.5
5 0.5
4.5 0.45
44 4.5
Torque value
N . m kgf . m
4.2 0.42
9 0.9
5.2 0.52
10 1.0
21.5 2.15
34 3.5
54 5.5
9 0.9
12 1.2
12 1.2
26 2.7
39 4.0
lbf . ft
25
25
25
119
58
2.5
6.1
3.6
1.0
3.6
1.8
2.2
1.8
8
5.8
5.8
3.6
3.6
3.6
3.6
3.3
33
lbf . ft
3.0
6.5
3.8
7
16
25
40
6.5
9
9
20
29
