Attaching a pen

Attach a pen to the pen station.
•
Please make sure to attach the pen to the pen station when setting up a pen.
•
To prevent injury, avoid touching the pen immediately after the cutting plotter is turned on or whenever the pen
is moving.
Operation
1
1. You can attach the pen by opening up the holder on the
pen station with your finger.
2
Once the pen is attached, releasing the holder fixes the pen
in place.

Removing a pen

You can remove the pen by lifting up the holder.
Holder
Always fit into grooves on the pen.
Supplement
Make sure to check that the top part of any
tools mounted on the pen station is set in the
grooves above the pen.
2-6
