Setting The Tool Up Speed - GRAPHTEC CE6000-120AP User Manual

7.5

Setting the Tool Up Speed

TOOL UP SPEED is the speed the tool moves when it is raised.
The cutting time in total becomes short if you set the TOOL UP SPEED to fast speed even though the speed of
the tool when it is cutting (lowered) is set to slow speed for the hard to cut media (hard or sticky).
Supplement
This setting will be saved even if the power is shut off.
Operation
1
Press the [PAUSE/MENU] key.
MENU screen is displayed.
2
Press the [1] key (TOOL).
TOOLS SETTING screen (1/3) is displayed.
3
Press the POSITION ( ) key.
TOOLS SETTING screen (2/3) is displayed.
4
Press the [3] key (TOOL UP SPEED).
TOOL UP SPEED setting screen is displayed.
5
Press the POSITION (
setting value.
) key and increase or decrease the
7-10
Supplement
Perform the settings in Normal menu.
Supplement
Values that can be set are AUTO, 10, 20, 30,
40, 50, and 60.
It will be same speed as tool is lowered when
AUTO is selected.
