Attaching a media guide

Assembly
1
Insert the cut-out part of the media guide onto the
components of the positioning pins at the bottom end of the
main assembly.
Attach both sides of the media guide using the 2 socket head
cap screw.
Media guide
Socket head cap
screw
Insert starting with the
cut-out components
1-11
Socket head cap
screw
