4
Press the POSITION (
setting value.
5
Confirm the setting and press the [ENTER] key (SET).
Setting will be set, and it will return to AREA PARAMETERS setting
screen (1/1).
6
Press the [PAUSE/MENU] key.
It will return to default screen.

Setting Length of the Page

Length of 1 page when using the roll media is set.
Only the part that will fit in to the set page length will be cut for the cutting data that is longer than the set page
length, and the exceeding part will not be cut.
Reference
Default page length is 3 m. When doing long cuts, set the page length. Check the setting of the page length when cutting long length.
* Be sure to use the basket.
For the CE6000-120AP, the page length up to 50 m can be set. We give quality assurance for page feeding up to 3 m. (Under the
condition that the media described below is used.)
• Be sure to use the basket.
• Media: genuine Graphtec brand products
• Setting Conditions: Speed under 30, acceleration under 2.
• Perform pre feed for the amount to be used before cutting.
• Leave the media in environment to use for adequate time if the deviation of temperature and humidity is big.
• Set the both push rollers at least 15mm inside the edge of media.
• The paper needs to be reset after cutting 5 consecutive pages.
• Each page should be removed from the basket after it has been cut.
When setting media for long-plotting, set the tension on the left and right of the width of the media to a uniform value. If it is not
uniform, the media may be removed from the roller that presses it during plotting.
Make sure to level the whole of the media to get rid of unevenness before cutting. (See "Setting the number of pre feeds"
Also, pre feeding can be done automatically when the data is received (see "Perform Automatic Pre Feed When Cut Data is
Received"
P.7-4
Feed)" ).
P.7-6
* Pre feeding will stabilize the feed by acclimating the media, taking out the slack.
This setting is maintained even after the power is turned off.
Operation
1
Press the [PAUSE/MENU] key.
MENU screen is displayed.
MENU screen
(Normal menu)
) key and increase or decrease the
), or done automatically when the media is loaded (see "Perform Automatic Pre Feed When Media is Set (Initial
MENU screen
(Simple menu)
4-5
Supplement
If the settings value is set to an area between
+1.0 mm and +10.00 mm, transfer direction of
the cutting area will also expand 5 mm forward.
The default area which can be set is +10.0 to
-10.0 mm.
Supplement
It will return to AREA PARAMETER screen (1/1)
without changing the settings when you press
the POSITION ( ) key (CANCEL).
).
P.4-7
