4
Press the [2] key (AXIS).
AXIS ALIGNMENT screen (1/1) is displayed.
5
Press [1] key (AXIS POINT SETTING).
The following message is displayed.
6
Press the POSITION (
to the alignment registration mark position.
Move the tool to adjustment point 1 (any point that is already plotted on
the X axis).
7
Press [ENTER] key to check the tool position.
8
Press the POSITION (
to the alignment registration mark position.
Move the tool to adjustment point 2 (any point that is already plotted on
the X axis).
9
Confirm the position of tool and then press [ENTER] key.
10
Press the POSITION (
to the alignment registration mark position.
Move the tool to a new origin (the desired origin point).
) keys to move the tip of the tool
) keys to move the tip of the tool
) keys to move the tip of the tool
5-4
Supplement
Tool carriage will move faster when the
[FAST] key is pressed simultaneously with the
POSITION key.
Supplement
Press the [4] key (CANCEL) to return to the
default screen without reading.
Supplement
Tool carriage will move faster when the
[FAST] key is pressed simultaneously with the
POSITION key.
Supplement
PPress the [4] key (CANCEL) to return to the
default screen without reading.
Supplement
Tool carriage will move faster when the
[FAST] key is pressed simultaneously with the
POSITION key.
