Align the receiving end of the media shaft with the grooves
on the roller and push down firmly to set it in place.
Stock shaft
Lever
Please make sure to set in the direction of the paper.
4
The left and right media flanges feed in the paper roll media.
Please tighten the flange screw and fasten the paper roll into
the desired position.
5
Lower the media set lever to raise the push rollers.
Lever
Roller
push rollers
Media set lever
2-9
CAUTION
During a plotting or cutting operation, be sure
to keep your hands, hair, and so forth away
from the media stocker, gears and rollers.
When you are installing media, be careful for
gear, a roller, etc. not pinch you finger.
Deviations and errors may result if the stock
shaft is misaligned when plotting begins.
