Perform Automatic Pre Feed When Cut
7.2
Data is Received
It is possible to feed and reverse the media automatically for specified amount when the plotter receives the
cutting data.
"Pre feeding" to prevent the shifting of media can be done automatically. Also, the media will be unrolled from the
roll before cutting when rolled media is to be used.
P.7-6 "Perform Automatic Pre Feed When Media is Set (Initial Feed)"
P.7-8 "Setting Feed Speed for Pre Feed"
Supplement
The setting for AUTO PRE FEED when cutting data is received is maintained even if the power is turned off.
Setting of the AUTO PRE FEED length is not linked to the setting of the page length. Change the setting for the page length if the
cutting area is to be long.
If data is received and auto media transfer is performed once, even if (cut in the same area) data is received again, auto media
transfer will not take place.
Operation
1
Press the [PAUSE/MENU] key.
MENU screen is displayed.
2
Press the [4] key (MEDIA).
MEDIA SETTING screen (1/3) is displayed.
3
Press the POSITION ( ) key.
MEDIA SETTING screen (2/3) is displayed.
4
Press the [2] key (AUTO PRE FEED).
AUTO PRE FEED screen is displayed.
Supplement
Perform the settings in Normal menu.
7-4
