1.3

Assembling

Assemble the stand.
The stand is made up of the following parts.

Components of stand

Stand side bar L × 1
(with media stocker)
Media flange × 2
Media guide × 1

Components of basket

Sheet supporting pipe (long) × 2
Sheet supporting pipe (short) × 4
Stand side bar R × 1
(with media stocker)
Base assembly × 2
Stock shaft × 1
Sheet supporting pipe (middle) x 1
Joint × 4
Center bar × 1
Media guide bar × 1
Supporting pipe plate × 2
1-5
Socket head cap screw
(M5) × 22
Allen wrench
(for M5 cap screw) × 1
Basket × 1
M5 screw × 4
