Parameter Description

3.11 DN-## DeviceNet

3.11.1 DN-0# Common Settings
DN-00 DeviceNet Protocol
3 3
Option:
[1] DeviceNet
*
DN-01 Baud Rate Select
Option:
[16] 10 Kbps
[17] 20 Kbps
[18] 50 Kbps
[19] 100 Kbps
[20] 125 Kbps
*
[21] 250 Kbps
[22] 500 Kbps
[23] 800 Kbps
[24] 1000 Kbps
DN-02 MAC ID
Range:
63 [0 - 63] Selection of station address. Every station
*
DN-05 Readout Transmit Error Counter
Range:
0 [0 - 255] Shows the number of CAN control transmission
*
DN-06 Readout Receive Error Counter
Range:
0 [0 - 255] Shows the number of CAN control receipt errors
*
DN-07 Readout Bus Off Counter
Range:
0 [0 - 255] View the number of network off events since the
*
94
Function:
NOTICE
The parameter options depend on
installed option.
View the active CAN protocol.
Function:
Select the network transmission speed. The
selection must correspond to the transmission
speed of the master and the other network
nodes.
Function:
connected to the same DeviceNet network must
have an unambiguous address.
Function:
errors since the last power-up.
Function:
since the last power-up.
Function:
last power-up.
3.11.2 DN-1# DeviceNet
DN-10 Process Data Type Selection
Option:
[0] INSTANCE
*
100/150
[1] INSTANCE
101/151
[2] INSTANCE
20/70
[3] INSTANCE
21/71
DN-11 Process Data Config Write
Option:
[0] None
*
[7] Accel Time 1
[8] Decel Time 1
[15] Motor Speed High Limit [Hz]
[16] Motor Speed Low Limit [Hz]
[17] Motor Speed High Limit [RPM]
[18] Motor Speed Low Limit [RPM]
[40] Torque Limiter (Driving)
[41] Torque Limiter (Braking)
[52] Minimum Reference
03/2016 All rights reserved.
Function:
Select the instance (message) for data
transmission. The instances available depend
on the setting of parameter O-10 Control
Word Profile.
When parameter O-10 Control Word Profile is
set to [0] Drive protocol,
parameter DN-10 Process Data Type Selection
options [0] INSTANCE 100/150 and [1]
INSTANCE 101/151 are available.
When parameter O-10 Control Word Profile is
set to [5] ODVA, parameter DN-10 Process
Data Type Selection options [2] INSTANCE
20/70 and [3] INSTANCE 21/71 are available.
Instances 100/150 and 101/151 are GE-
specific. Instances 20/70 and 21/71 are
ODVA-specific AC motor profiles.
For guidelines in message selection, refer to
the DeviceNet MCA 104 Installation Guide.
NOTICE
A change to this parameter is executed
immediately.
Function:
Select the process
write data for I/O
assembly instances
101/151. Elements 2
and 3 of this array
can be selected.
Elements 0 and 1 of
the array are fixed.
