Parameter Description
F-93 Maximum Limit
Range:
100 % [-200 -
*
200 %]
3 3
F-94 Minimum Limit
Range:
0 % [-200 -
*
200 %]
F-95 Accel/Decel Ramp Delay
Range:
0.000 [0.000 -
*
0.000]
Illustration 3.13 Ramp Delay Case 1
Illustration 3.14 Ramp Delay Case 2
42
Function:
Set the maximum permissible value for the
resulting reference. This is recommended if
the digital pot-meter is used for fine-tuning
of the resulting reference.
Function:
Set the minimum permissible value for the
resulting reference. This is advisable if the
digital pot-meter is used for fine-tuning of
the resulting reference.
Function:
Enter the delay required from activation of the
digital potentiometer function until the
frequency converter starts to ramp the
reference. With a delay of 0 ms, the reference
starts to ramp as soon as increase/decrease is
activated. See also parameter F-91 Accel/Decel
Time.
