Parameter Description
E-65 Term. 33 Low Frequency
Range:
100 Hz [0 - 110000
*
Hz]
3 3
E-66 Term. 33 High Frequency
Range:
100 Hz [0 - 110000
*
Hz]
E-67 Term. 33 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999]
E-68 Term. 33 High Ref./Feedb. Value
Range:
100 [-999999.999 -
*
999999.999]
E-69 Pulse Filter Time Constant #33
Range:
100 [1 - 1000
ms ms]
*
3.3.5 E-7# Pulse Output
E-70 Terminal 27 Pulse Output Variable
Option:
[0] No operation
*
[45] Bus ctrl.
[48] Bus ctrl., timeout
[100] Output frequency
[101] Reference
50
Function:
Enter the low frequency corresponding
to the low motor shaft speed (that is
low reference value) in
parameter E-67 Term. 33 Low Ref./Feedb.
Value.
Function:
Enter the high frequency corresponding
to the high motor shaft speed (that is
high reference value) in
parameter E-68 Term. 33 High Ref./Feedb.
Value.
Function:
Enter the low reference value [RPM] for
the motor shaft speed. This is also the
low feedback value, see also
parameter E-62 Term. 29 Low Ref./Feedb.
Value.
Function:
Enter the high reference value [RPM]
for the motor shaft speed. See also
parameter E-63 Term. 29 High Ref./
Feedb. Value.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Enter the pulse filter time constant. The
low-pass filter reduces the influence, and
dampens oscillations on the feedback
signal from the control.
This is an advantage if there is a great
amount of noise in the system.
Function:
03/2016 All rights reserved.
E-70 Terminal 27 Pulse Output Variable
Option:
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
E-71 Pulse Output Max Freq #27
Range: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
5000 Hz [0 - 32000 Set the maximum frequency for terminal
*
Hz] 27 corresponding to the output variable
selected in parameter E-70 Terminal 27
Pulse Output Variable.
E-72 Terminal 29 Pulse Output Variable
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Select the variable for viewing on
terminal 29. Same options and
functions as parameter group E-75.
[0] No operation
*
[45] Bus ctrl.
[48] Bus ctrl., timeout
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
E-74 Pulse Output Max Freq #29
Range: Function:
5000 Hz [0 - 32000 Set the maximum frequency for terminal
*
Hz] 29 corresponding to the output variable
set in parameter E-72 Terminal 29 Pulse
Output Variable.
