GE Ecomagination AF-600 FP Programming Manual page 191

Parameter Description
LC-40 Logic Rule Boolean 1
Array [6]
Option:
[100] Fire Mode
3 3
[140] ATEX ETR cur.
warning
[141] ATEX ETR cur.
alarm
[142] ATEX ETR freq.
warning
[143] ATEX ETR freq.
alarm
LC-41 Logic Rule Operator 1
Array [6]
Option:
[0] DISABLED
*
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND
NOT
[8] NOT OR
NOT
LC-42 Logic Rule Boolean 2
Array [6]
Option: Function:
Select the second boolean (TRUE or FALSE) input for
the selected logic rule.
See parameter LC-40 Logic Rule Boolean 1 for further
descriptions of choices and their functions.
190
Function:
See parameter LC-15 RS-FF Operand S,
parameter LC-16 RS-FF Operand R.
Function:
st
Select the 1 logical operator to use on the
boolean inputs from parameter LC-40 Logic
Rule Boolean 1 and parameter LC-42 Logic Rule
Boolean 2.
Parameter numbers in square brackets stand
for the boolean inputs of parameters in LC-##
Logic Controller .
Ignores:
•
Parameter LC-42 Logic Rule Boolean 2.
•
Parameter LC-43 Logic Rule Operator
2.
•
Parameter LC-44 Logic Rule Boolean 3.
Evaluates the expression [LC-40] AND [LC-42].
Evaluates the expression [LC-40] OR [LC-42].
Evaluates the expression [LC-40] AND NOT
[LC-42].
Evaluates the expression [LC-40] OR NOT
[LC-42].
Evaluates the expression NOT [LC-40] AND
[LC-42].
Evaluates the expression NOT [LC-40] OR
[LC-42].
Evaluates the expression NOT [LC-40] AND
NOT [LC-42].
Evaluates the expression NOT [LC-40] OR NOT
[LC-42].
LC-43 Logic Rule Operator 2
Array [6]
Option:
[0] DISABLED
*
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND
NOT
[8] NOT OR NOT
LC-44 Logic Rule Boolean 3
Array [6]
Option: Function:
Select the third boolean (TRUE or FALSE) input for the
selected logic rule.
See parameter LC-40 Logic Rule Boolean 1 for further
descriptions of choices and their functions.
03/2016 All rights reserved.
Function:
nd
Select the 2 logical operator to be used on
the boolean input calculated in:
•
Parameter LC-40 Logic Rule Boolean
1.
•
Parameter LC-41 Logic Rule Operator
1.
•
Parameter LC-42 Logic Rule Boolean
2.
and the boolean input coming from
parameter LC-42 Logic Rule Boolean 2.
[LC-44] signifies the boolean input of
parameter LC-44 Logic Rule Boolean 3.
[LC-40/LC-42] signifies the boolean input
calculated in:
•
Parameter LC-40 Logic Rule Boolean
1.
•
Parameter LC-41 Logic Rule Operator
1.
•
Parameter LC-42 Logic Rule Boolean
2.
Select this option to ignore
parameter LC-44 Logic Rule Boolean 3.
DET-620D
