GE Ecomagination AF-600 FP Programming Manual page 69

Parameter Description
H-76 Warning Feedback Low
Range:
-999999.999
ProcessCtrlUnit
3 3
H-77 Warning Feedback High
Range:
999999.999
ProcessCtrlUnit
H-78 Missing Motor Phase Function
Option:
[0] Disabled
[1] Trip 100 ms
[2] Trip 1000 ms
*
[3] Trip 100 ms lim 3
phase detec.
[5] Motor Check
3.6.7 H-8# Stop Adjustments
H-80 Function at Stop
Option:
68
Function:
[-999999.999 - Enter the lower feedback
par. H-77 limit. When the feedback
*
ProcessCtrlUnit] drops below this limit, the
display reads Feedb
signal outputs can be
programmed to produce a
status signal on terminal
27 or 29, and on relay
output 01 or 02.
Function:
[par. H-76 - Enter the upper
999999.999 feedback limit. When
*
ProcessCtrlUnit] the feedback exceeds
this limit, the display
reads Feedb
Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Shows an alarm if motor phase is
missing.
No alarm is shown if a missing motor
phase occurs.
An alarm is shown if a missing motor
phase occurs.
Function:
Select the frequency converter function after a
stop command or after the speed is deceled to
the settings in parameter H-81 Min Speed for
Function at Stop [RPM].
Available selections depend on
parameter P-20 Motor Construction:
[0] Asynchronous:
[0] Coast
[1] DC hold
H-80 Function at Stop
Option:
. The
Low
[0] Coast
*
[1] DC Hold/
Motor
Preheat
[2] Motor
check
[6] Motor
check,
alarm
H-81 Min Speed for Function at Stop [RPM]
.
High
Range:
3 RPM [0 - 600 RPM] Set the speed at which to activate
*
H-82 Min Speed for Function at Stop [Hz]
Range:
0.1 Hz [0 - 20.0 Hz] Set the output frequency at which to
*
3.6.8 H-9#
H-94 ATEX ETR cur.lim. speed reduction
Range:
0 %
*
H-98 ATEX ETR interpol. points freq.
Range:
0.0 Hz
*
H-99 ATEX ETR interpol points current
Range:
0 %
*
03/2016 All rights reserved.
Function:
[2] Motor check, warning
[6] Motor check, alarm
[1] PM non-salient:
[0] Coast
Leaves motor in free mode.
Energizes motor with a DC hold current (see
parameter B-00 DC Hold Current).
The frequency converter issues a warning if 1
or more phases are missing.
The frequency converter issues an alarm if 1 or
more phases are missing.
Function:
parameter H-80 Function at Stop.
Function:
activate parameter H-80 Function at Stop.
Function:
[0 - 100 %]
Function:
[0 - 1000.0 Hz]
Function:
[0 - 100 %]
DET-620D
