Parameter Description
3
3
[21]
Speed up
[22]
Speed
down
[23]
Set-up
select bit 0
[24]
Set-up
select bit 1
[32]
Pulse Input
[34]
Ramp bit 0
[36]
Line failure
inverse
[37]
Fire Mode
[52]
Run
permissive
44
NOTICE
When Freeze output is active, the
frequency converter cannot be
stopped via a low 'start [8]' signal.
Stop the frequency converter via a
terminal programmed for Coasting
inverse [2] or Coast and reset, inverse.
Select Speed up and Speed down if digital
control of the up/down speed is desired
(motor potentiometer). Activate this function
by selecting either Freeze reference or Freeze
output. When Speed up/ down is activated
for less than 400 msec. the resulting
reference will be increased/ decreased by
0.1 %. If Speed up/ down is activated for
more than 400 msec. the resulting reference
will follow the setting in accelling/decelling
parameters F-07, F-08, E-10 and E-11.
Shut
down
Unchanged speed
0
Reduced by %-value
1
Increased by %-value
0
Reduced by %-value
1
Table 3.6
Same as Speed up [21].
Select Set-up select bit 0 or Select Set-up
select bit 1 to select one of the four set-ups.
Set parameter K-10 Active Set-up.
Same as Set-up select bit 0 [23].
Select Pulse input when using a pulse
sequence as either reference or feedback.
Enables a choice between one of the 4
ramps available, according to the table
below.
Activates parameter SP-10 Line failure. Mains
failure inverse is active in the Logic .0.
situation.
A signal applied will put the frequency
converter into Fire Mode and all other
commands will be disregarded. See FB-0#
Fire Mode.
The input terminal, for which the Run
permissive has been programmed must be
logic "1" before a start command can be
accepted. Run permissive has a logic 'AND'
function related to the terminal which is
programmed for START [8], Jog [14] or Freeze
Output [20], which means that in order to
start running the motor, both conditions
must be fulfilled. If Run Permissive is
programmed on multiple terminals, Run
03/2016 All rights reserved.
[53]
Hand start
Catch
up
0
0
1
1
[54]
Auto start
[55]
DigiPot
increase
[56]
DigiPot
decrease
[57]
DigiPot
clear
[62]
Reset
Counter A
[65]
Reset
Counter B
[66]
Sleep Mode Forces frequency converter into Sleep Mode
[78]
Reset Maint.
Word
[120] Lead Pump
Start
[121] Lead Pump
Alternation
permissive needs only be logic '1' on one of
the terminals for the function to be carried
out. The digital output signal for Run
Request (Start [8], Jog [14] or Freeze output
[20]) will not be affected by Run Permissive.
NOTICE
If no Run Permissive signal is applied
but either Run, Jog or Freeze
commands is activated, the status line
in the display will show either Run
Requested, Jog Requested or Freeze
Requested.
A signal applied will put the frequency
converter into Hand mode as if button Hand
on the keypad has been pressed and a
normal stop command will be overridden. If
disconnecting the signal, the motor will stop.
To make any other start commands valid,
another digital input must be assign to Auto
Start and a signal applied to this. The Hand
and Auto buttons on the keypad has no
impact. The Off button on the keypad will
override Hand Start and Auto Start. Press
either the Hand or Auto button to make
Hand Start and Auto Start active again. If no
signal on neither Hand Start nor Auto Start,
the motor will stop regardless of any normal
Start command applied. If signal applied to
both Hand Start and Auto Start, the function
will be Auto Start. If pressing the Off button
on the keypad the motor will stop regardless
of signals on Hand Start and Auto Start.
A signal applied will put the frequency
converter into Auto mode as if the keypad
button Auto has been pressed. See also Hand
Start [53]
INCREASE signal to the Digital Potentiometer
function described in parameter group F-9#
DECREASE signal to the Digital Potentiometer
function described in parameter group F-9#
Clears the Digital Potentiometer reference
described in parameter group F-9#
Input for reset of counter A.
Input for reset of counter B.
(see parameter group AP-4#). Reacts on the
rising edge of signal applied.
Resets all data in
parameter DR-96 Maintenance Word to 0.
