Parameter Description
O-50 Coasting Select
Option: Function:
Select the trigger for the coasting function.
[0] Digital A digital input triggers the coasting function.
input
[1] Bus A serial communication port or the network
option module triggers the coasting function.
[2] Logic AND The network/serial communication port and a
digital input trigger the coasting function.
[3] Logic OR The network/serial communication port or a
*
digital input trigger the coasting function.
O-52 DC Brake Select
Option: Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
When parameter P-20 Motor Construction is
set to [1] PM non-salient SPM, only
selection [0] Digital input is available.
[0] Digital Activates a DC Brake command via a digital
input input.
[1] Bus Activates a DC Brake command via the serial
communication port or network option module.
[2] Logic Activates a DC Brake command via the network/
AND serial communication port, and also via 1 of the
digital inputs.
[3] Logic OR Activates a DC Brake command via the network/
*
serial communication port, or via 1 of the digital
inputs.
O-53 Start Select
Option: Function:
Select the trigger for the start function.
[0] Digital A digital input triggers the start function.
input
[1] Bus A serial communication port or the network
option module triggers the start function.
[2] Logic AND The network/serial communication port and a
digital input trigger the start function.
[3] Logic OR The network/serial communication port or a
*
digital input trigger the start function.
O-54 Reversing Select
Option: Function:
NOTICE
This parameter is active only when
parameter O-01 Control Site is set to [0]
Digital and control word.
DET-620D
AF-600 FP™ Programming Guide
O-54 Reversing Select
Option:
[0] Digital
*
input
[1] Bus
[2] Logic
AND
[3] Logic
OR
O-55 Set-up Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
O-56 Preset Reference Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
03/2016 All rights reserved.
Function:
Select control of the drive reverse function via
the terminals (digital input) and/or via the
fieldbus.
Activates reverse command via a digital input.
Activates reverse command via the serial
communication port or fieldbus option.
Activates reverse command via the fieldbus/serial
communication port, AND via 1 of the digital
inputs.
Activates reverse command via the fieldbus/serial
communication port OR via 1 of the digital
inputs.
Function:
Select the trigger for the set-up selection.
A digital input triggers the set-up selection.
A serial communication port or the network
option module triggers the set-up selection.
The network/serial communication port and a
digital input trigger the set-up selection.
The network/serial communication port or a
digital input trigger the set-up selection.
Function:
Select the trigger for the preset reference
selection.
A digital input triggers the preset reference
selection.
A serial communication port or the network
option module triggers the preset reference
selection.
The network/serial communication port and a
digital input trigger the preset reference
selection.
The network/serial communication port or a
digital input trigger the preset reference
selection.
