Parameter Description

E-75 Terminal X30/6 Pulse Output Variable

Option:

Function:

NOTICE

This parameter cannot be

adjusted while the motor is

running.

Select the maximum frequency on

terminal X30/6 referring to the output

variable in parameter E-75 Terminal

X30/6 Pulse Output Variable.

This parameter is active when General

Purpose I/O OPCGPIO General Purpose

I/O is installed in the frequency

converter.

[0]

No operation

[45]

Bus ctrl.

[48]

Bus ctrl., timeout

[100] Output frequency

[101] Reference

[102] Feedback

[103] Motor Current

[104] Torque rel to limit

[105] Torq relate to rated

[106] Power

[107] Speed

[113] Ext. Closed Loop 1

[114] Ext. Closed Loop 2

[115] Ext. Closed Loop 3

E-76 Pulse Output Max Freq #X30/6

Range:

5000 Hz

[0 - 32000 Hz]

3.3.6 E-9# Bus-Controlled

This parameter group selects digital and relay outputs via a

fieldbus setting.

E-90 Digital & Relay Bus Control

Range:

Function:

[0 -

This parameter holds the state of the

2147483647]

digital outputs and relays that is controlled

by bus.

A logical 1 indicates that the output is high

or active.

A logical 0 indicates that the output is low

or inactive.

DET-620D

AF-600 FP™ Programming Guide

E-90 Digital & Relay Bus Control

Range:

E-93 Pulse Out #27 Bus Control

Range:

0 %

E-94 Pulse Out #27 Timeout Preset

Range:

0 %

E-95 Pulse Out #29 Bus Control

Function:

Range:

0 %

E-96 Pulse Out #29 Timeout Preset

Range:

0 %

E-97 Pulse Out #X30/6 Bus Control

Range:

0 %

Function:

Bit 0

CC Digital Output Terminal 27

Bit 1

CC Digital Output Terminal 29

Bit 2

GPIO Digital Output Terminal X

30/6

Bit 3

GPIO Digital Output Terminal X

30/7

Bit 4

CC Relay 1 output terminal

Bit 5

CC Relay 2 output terminal

Bit 6

Option B Relay 1 output terminal

Bit 7

Option B Relay 2 output terminal

Bit 8

Option B Relay 3 output terminal

Bit 9-31 Reserved for future terminals

Table 3.8

Function:
