Parameter Description
[1252] Feedback [Unit] Reference value from programmed
[1253] Digi Pot
Reference
[1254] Feedback 1
3 3
[Unit]
[1255] Feedback 2
[Unit]
[1256] Feedback 3
[Unit]
[1258] PID Output [%]
[1260] Digital Input
[1261] Terminal 53
Switch Setting
[1262] Analog Input
53
[1263] Terminal 54
Switch Setting
[1264] Analog Input
54
[1265] Analog Output
42 [mA]
[1266] Digital Output
[bin]
[1267] Freq. Input #29
[Hz]
[1268] Freq. Input #33
[Hz]
[1269] Pulse Output
#27 [Hz]
[1270] Pulse Output
#29 [Hz]
[1271] Relay Output
[bin]
[1272] Counter A
[1273] Counter B
[1275] Analog In
X30/11
[1276] Analog In
X30/12
[1277] Analog Out
X30/8 [mA]
[1280] Fieldbus CTW 1 Control word (CTW) received from the
[1282] Fieldbus REF 1
28
digital input(s).
View the contribution of the digital
potentiometer to the actual reference
Feedback.
View the value of Feedback 1. See also
par. CL-0#.
View the value of Feedback 2. See also
par. CL-0#.
View the value of Feedback 3. See also
par. CL-0#.
Returns the Drive Closed Loop PID
controller output value in percent.
Displays the status of the digital inputs.
Signal low = 0; Signal high = 1.
Regarding order, see
parameter DR-60 Digital Input. Bit 0 is at
the extreme right.
Setting of input terminal 53. Current =
0; Voltage = 1.
Actual value at input 53 either as a
reference or protection value.
Setting of input terminal 54. Current =
0; Voltage = 1.
Actual value at input 54 either as
reference or protection value.
Actual value at output 42 in mA. Use
parameter AN-50 Terminal 42 Output to
select the variable to be represented by
output 42.
Binary value of all digital outputs.
Actual value of the frequency applied at
terminal 29 as a pulse input.
Actual value of the frequency applied at
terminal 33 as a pulse input.
Actual value of pulses applied to
terminal 27 in digital output mode.
Actual value of pulses applied to
terminal 29 in digital output mode.
View the setting of all relays.
View the present value of Counter A.
View the present value of Counter B.
Actual value at input X30/11 either as
reference or protection value.
Actual value at input X30/12 either as
reference or protection value.
Actual value at output X30/8 in mA. Use
par. AN-60 to select the value to be
shown.
Bus Master.
Main reference value sent with control
word via the serial communications
03/2016 All rights reserved.
network e.g. from the BMS, PLC or other
master controller.
[1284] Comm. Option Extended fieldbus communication
STW option status word.
[1285] Drive Port CTW Control word (CTW) received from the
1 Bus Master.
[1286] Drive Port REF Status word (STW) sent to the Bus
1 Master.
[1290] Alarm Word One or more alarms in a Hex code
(used for serial communications)
[1291] Alarm Word 2 One or more alarms in a Hex code
(used for serial communications)
[1292] Warning Word One or more warnings in a Hex code
(used for serial communications)
[1293] Warning Word One or more warnings in a Hex code
2 (used for serial communications)
[1294] Ext. Status One or more status conditions in a Hex
Word code (used for serial communications)
[1295] Ext. Status One or more status conditions in a Hex
Word 2 code (used for serial communications)
[1296] Maintenance The bits reflect the status for the
Word programmed Preventive Maintenance
Events in parameter group T-1#
[1830] Analog Input Shows the value of the signal applied to
X42/1 terminal X42/1 on the Analog I/O card.
[1831] Analog Input Shows the value of the signal applied to
X42/3 terminal X42/3 on the Analog I/O card.
[1832] Analog Input Shows the value of the signal applied to
X42/5 terminal X42/5 on the Analog I/O card.
[1833] Analog Out Shows the value of the signal applied to
X42/7 [V] terminal X42/7 on the Analog I/O card.
[1834] Analog Out Shows the value of the signal applied to
X42/9 [V] terminal X42/9 on the Analog I/O card.
[1835] Analog Out Shows the value of the signal applied to
X42/11 [V] terminal X42/11 on the Analog I/O card.
[2117] Ext. 1 Reference The value of the reference for extended
[Unit] Closed Loop Controller 1
[2118] Ext. 1 Feedback The value of the feedback signal for
[Unit] extended Closed Loop Controller 1
[2119] Ext. 1 Output The value of the output from extended
[%] Closed Loop Controller 1
[2137] Ext. 2 Reference The value of the reference for extended
[Unit] Closed Loop Controller 2
[2138] Ext. 2 Feedback The value of the feedback signal for
[Unit] extended Closed Loop Controller 2
[2139] Ext. 2 Output The value of the output from extended
[%] Closed Loop Controller 2
[2157] Ext. 3 Reference The value of the reference for extended
[Unit] Closed Loop Controller 3
[2158] Ext. 3 Feedback The value of the feedback signal for
[Unit] extended Closed Loop Controller 3
[2159] Ext. 3 Output The value of the output from extended
[%] Closed Loop Controller 3
[1230] No-Flow Power The calculated No Flow Power for the
actual operating speed
