Troubleshooting

4.1.2 Alarm Words

Bit
(hex)
00000001
00000002
00000004
00000008
4 4
00000010
00000020
00000040
00000080
00000100
00000200
00000400
00000800
00001000
00002000
00004000
00008000
00010000
00020000
00040000
00080000
00100000
00200000
00800000
01000000
02000000
04000000
08000000
10000000
20000000
80000000
Table 4.3 Parameter DR-90 Alarm Word
200
Alarm word
(parameter DR-90 Alarm Word)
Power card over temperature
Earth fault
Control word timeout
Over current
Motor thermistor over temp.
Motor Electronic Thermal Overload over
temperature
Inverter overloaded
DC link under voltage
DC link over voltage
Short circuit
Mains phase loss
Auto Tune not OK
Live zero error
Internal fault
Motor phase U is missing
Motor phase V is missing
Motor phase W is missing
Control Voltage Fault
VDD, supply low
Not used
Not used
Earth fault DESAT
Drive restored
03/2016 All rights reserved.
Bit Alarm word 2
(hex) (parameter DR-91 Alarm Word 2)
00000001
00000002 Reserved
00000004 Service Trip, Typecode / Sparepart
00000008 Reserved
00000010 Reserved
00000020
00000040
00000080
00000100 Broken Belt
00000200 Not used
00000400 Not used
00000800 Reserved
00001000 Reserved
00002000 Reserved
00004000 Reserved
00008000 Reserved
00010000 Reserved
00020000 Not used
00040000 Fans error
00080000 Reserved
00100000 Reserved
00200000 Reserved
00400000 Reserved
00800000 Reserved
01000000 Reserved
02000000 Reserved
04000000 Reserved
08000000 Reserved
10000000 Reserved
20000000 Reserved
Table 4.4 Parameter DR-91 Alarm Word 2
