Parameter Description
CL-20 Feedback Function
Option:
3 3
[4] Maximum Sets up the PID controller to compare feedback
[5] Multi
Setpoint
Min
158
Function:
NOTICE
Set any unused feedbacks to [0] No
Function in
•
Parameter CL-00 Feedback 1
Source.
•
Parameter CL-03 Feedback 2
Source.
•
Parameter CL-06 Feedback 3
Source.
Only setpoint 1 is used. The sum of
setpoint 1 and any other references that
are enabled (see C-30 and C-34) are used
as the PID controller's setpoint reference.
1, feedback 2, and feedback 3 and use the
highest value as the feedback.
NOTICE
Set any unused feedbacks to [0] No
Function in
•
Parameter CL-00 Feedback 1
Source.
•
Parameter CL-03 Feedback 2
Source.
•
Parameter CL-06 Feedback 3
Source.
Only setpoint 1 is used. The sum of setpoint 1
and any other references that are enabled (see
C-30 and C-34) are used as the PID controller's
setpoint reference.
Sets up the PID controller to calculate the
difference between feedback 1 and setpoint 1,
feedback 2 and setpoint 2, and feedback 3 and
setpoint 3. It uses the feedback/setpoint pair in
which the feedback is the farthest below its
corresponding setpoint reference. If all feedback
signals are above their corresponding setpoints,
the PID controller uses the feedback/setpoint pair
with the least difference between the 2.
CL-20 Feedback Function
Option:
[6] Multi
Setpoint
Max
03/2016 All rights reserved.
Function:
NOTICE
If only 2 feedback signals are used, set the
non-used feedback to [0] No Function in
•
Parameter CL-00 Feedback 1
Source.
•
Parameter CL-03 Feedback 2
Source.
•
Parameter CL-06 Feedback 3
Source.
Note that each setpoint reference is the
sum of its respective parameter value
(parameter CL-21 Setpoint 1,
parameter CL-22 Setpoint 2, and
parameter CL-23 Setpoint 3) and any other
references that are enabled (see C-30 and
C-34).
Sets up the PID controller to calculate the
difference between feedback 1 and setpoint 1,
feedback 2 and setpoint 2, and feedback 3 and
setpoint 3. It uses the feedback/setpoint pair in
which the feedback is farthest above its
corresponding setpoint reference. If all feedback
signals are below their corresponding setpoints,
the PID controller uses the feedback/setpoint pair
with the least difference between the 2.
NOTICE
If only 2 feedback signals are used, set the
non-used feedback to [0] No Function in
•
Parameter CL-00 Feedback 1
Source.
•
Parameter CL-03 Feedback 2
Source.
•
Parameter CL-06 Feedback 3
Source.
Note that each setpoint reference is the
sum of its respective parameter value
(parameter CL-21 Setpoint 1,
parameter CL-22 Setpoint 2, and
parameter CL-23 Setpoint 3) and any other
references that are enabled (see parameter
group C-30 and C-34).
