Parameter Description
O-13 Configurable Status Word STW
Array [16]
Option:
3 3
[85] SL digital out
F
[86] ATEX ETR cur.
alarm
[87] ATEX ETR freq.
alarm
[88] ATEX ETR cur.
warning
[89] ATEX ETR freq.
warning
Activate or deactivate the storing of data in non-volatile
memory.
O-16 Store Data Values
Option:
[0] Off
*
[1] Store edit setup
[2] Store all setups
O-19 Product Code
Range:
0 [0 - 2147483647] Select 0 to read out the actual fieldbus
*
3.9.3 O-3# Drive Port Settings
O-30 Protocol
Option:
[0] Drive
*
[1] Drive
MC
84
Function:
smart logic action [36] Set digital out E low
is executed.
See parameter LC-52 Logic Controller Action.
The input goes high whenever the smart
logic action [43] Set digital out F high is
executed. The input goes low whenever the
smart logic action [37] Set digital out F low
is executed.
Function:
Function:
product code according to the mounted
fieldbus option. Select 1 to read out the
actual vendor ID.
Function:
Protocol selection for the integrated Drive
(standard) Port (RS485) on the control card.
Parameter group BN-7# is only visible when [9]
Drive Option is selected.
Communication according to the Drive Protocol
as described in the AF-600 FP AF-600 FP Design
Guide, RS485 Installation and Set-up.
Same as [0] Drive but to be used when
downloading SW to the drive or uploading dll file
(covering information regarding parameters
available in the drive and their inter-depend-
encies) to DCT-10.
O-30 Protocol
Option:
[2] Modbus
RTU
[3] Metasys
N2
[4] FLN
[9] Drive
Option
[20] LEN
O-31 Address
Range:
1 [1 - 255]
*
O-32 Drive Port Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
*
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
O-33 Drive Port Parity
Option:
03/2016 All rights reserved.
Function:
Communication according to the Modbus RTU
protocol as described in the AF-600 FP AF-600 FP
Design Guide, RS485 Installation and Set-up.
Communication according to the Metasys N2
protocal.
Communication according to the Apogee FLN P1
protocol.
To be used when a gateway is connected to the
integrated RS485 port, for example the BACnet
gateway.
Following changes take place:
•
Address for the Drive port is set to 1,
and parameter O-31 Address, is now
used to set the address for the gateway
on the network, for example BACnet.
•
Baud rate for the Drive port is set to a
fixed value (115.200 Baud), and
parameter O-32 Drive Port Baud Rate, is
now used to set the baud rate for the
network port (for example BACnet) on
the gateway.
Function:
Enter the address for the Drive (standard) port.
Valid range: 1–126.
Function:
Baud rates 9600, 19200, 38400, and 76800
baud are valid for BACnet only.
The default value depends on the Drive
protocol.
Function:
Parity and stop bits for the protocol
parameter O-30 Protocol using the Drive
port. For some of the protocols, not all
options are visible. Default depends on
the protocol selected.
