Parameter Description

3.10 AO-## Analog I/O Options

Parameter group AO-## is only available when an Analog
I/O Option Module (opcaio) is added to the frequency
converter.
3.10.1 AO-0# Analog I/O Mode
AO-00 Terminal X42/1 Mode
Option: Function:
Terminal X42/1 can be programmed as an
analog input accepting a voltage or input
from either Pt1000 (1000 Ω at 0 °C) or Ni
1000 (1000 Ω at 0 °C) temperature sensors.
Select the mode.
°
[2] Pt 1000 [
operating in Celsius, or [3] Pt 1000 [
°
Ni 1000 [ F] if operating in Fahrenheit.
NOTICE
If the input is not in use, set it for
voltage.
If set for temperature and used as feedback,
set the unit for either Celsius or Fahrenheit.
•
Parameter CL-12 Reference/Feedback
Unit.
•
Parameter XC-10 Ext. 1 Ref./Feedback
Unit.
•
Parameter XC-30 Ext. 2 Ref./Feedback
Unit.
•
Parameter XC-50 Ext. 3 Ref./Feedback
Unit.
[1] Voltage
*
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
AO-01 Terminal X42/3 Mode
Option: Function:
Terminal X42/3 can be programmed as an
analog input accepting a voltage, or input
from either Pt 1000 or Ni 1000 temperature
sensors. Select the mode.
°
[2] Pt 1000 [
operating in Celsius, or [3] Pt 1000 [
°
Ni 1000 [ F] if operating in Fahrenheit.
NOTICE
If the input is not in use, set it for
voltage.
If set for temperature and used as feedback,
set the unit for either Celsius or Fahrenheit
DET-620D
AF-600 FP™ Programming Guide
°
C] and [4] Ni 1000 [ C] if
°
F] and [5]
°
C] and [4] Ni 1000 [ C] if
°
F] and [5]
03/2016 All rights reserved.
AO-01 Terminal X42/3 Mode
Option: Function:
•
Parameter CL-12 Reference/Feedback
Unit.
•
Parameter XC-10 Ext. 1 Ref./Feedback
Unit.
•
Parameter XC-30 Ext. 2 Ref./Feedback
Unit.
•
Parameter XC-50 Ext. 3 Ref./Feedback
Unit.
[1] Voltage
*
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
AO-02 Terminal X42/5 Mode
Option: Function:
Terminal X42/5 can be programmed as an
analog input accepting a voltage or input
from either Pt 1000 (1000 Ω at 0 °C) or Ni
1000 (1000 Ω at 0 °C) temperature sensors.
Select the mode.
°
[2] Pt 1000 [ C] and [4] Ni 1000 [
operating in Celsius, or [3] Pt 1000 [
°
Ni 1000 [ F] if operating in Fahrenheit.
NOTICE
If the input is not in use, set it for
voltage.
If set for temperature and used as feedback,
set the unit for either Celsius or Fahrenheit:
•
Parameter CL-12 Reference/Feedback
Unit.
•
Parameter XC-10 Ext. 1 Ref./Feedback
Unit.
•
Parameter XC-30 Ext. 2 Ref./Feedback
Unit.
•
Parameter XC-50 Ext. 3 Ref./Feedback
Unit.
[1] Voltage
*
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
3 3
°
C] if
°
F] and [5]
89
