Parameter Description
DR-38 Logic Controller State
Range: Function:
0 [0 - 100] View the state of the event under execution by
*
the Logic controller.
DR-39 Control Card Temp.
Range: Function:
0 °C [0 - 100 °C] View the temperature on the control card,
*
stated in °C.
DR-40 Trending Buffer Full
Option: Function:
View whether the logging buffer is full (see
chapter 3.16.2 ID-1# Data Trending Settings). The
logging buffer is never full when
parameter ID-13 Trending Mode is set to [0] Log always.
[0] No
*
[1] Yes
DR-41 Keypad Bottom Statusline
Range:
0 [0 - 50]
*
DR-43 Timed Actions Status
View the timed actions mode.
Option:
[0] Timed Actions Auto
*
[1] Timed Actions Disabled
[2] Constant On Actions
[3] Constant Off Actions
DR-49 Current Fault Source
Range: Function:
0 [0 - 8] The value indicates source of current fault,
*
including:
•
Short circuit.
•
Overcurrent.
•
Phase imbalance (from left): 1–4 – inverter,
5–8 – rectifier, 0 – no fault recorded.
After a short circuit alarm (I
max2
or imbalance of supply voltage, this contains the power
card number associated with the alarm. It only holds 1
number indicating the highest priority power card number
(master first). The value persists on power cycle, but if a
new alarm occurs it is overwritten by the new power card
number (even if it is a lower priority number). The value is
only cleared when the alarm log is cleared (that is a 3-
finger reset would reset the readout to 0).
DET-620D
AF-600 FP™ Programming Guide
Function:
Function:
) or overcurrent alarm (I )
max1
03/2016 All rights reserved.
3.17.4 DR-5# Ref. & Feedb.
DR-50 External Reference
Range: Function:
0 [-200 - 200] View the total reference, the sum of digital,
*
analog, preset, fieldbus, and freeze references,
plus catch up and slow down.
DR-52 Feedback[Unit]
Range:
0 [-999999.999
ProcessCtrlUnit - 999999.999
*
ProcessCtrlUnit]
DR-53 Digi Pot Reference
Range: Function:
0 [-200 - 200] View the contribution of the digital Pot. meter
*
to the actual reference.
DR-54 Feedback 1 [Unit]
Range:
0 [-999999.999 -
ProcessCtrlUnit 999999.999
*
ProcessCtrlUnit]
Function:
View value of resulting feedback
value after processing of feedback
1-3 see
•
Parameter DR-54 Feedback
1 [Unit].
•
Parameter DR-55 Feedback
2 [Unit].
•
Parameter DR-56 Feedback
3 [Unit].
in the feedback manager.
See parameter group CL-0#
Feedback.
The value is limited by settings in
parameter F-52 Minimum Reference
and parameter F-53 Maximum
Reference. Units as set in
parameter CL-12 Reference/
Feedback Unit.
Function:
View value of feedback 1.
The value is limited by
settings in F-53 and F-54.
Units as set in
parameter CL-12 Reference/
Feedback Unit.
