Parameter Description
LC-52 Logic Controller Action
Array [20]
Option: Function:
[90] Set ECB Bypass
Mode
[91] Set ECB Drive
Mode
[100] Reset Alarms
3.25.7 LC-9#
LC-90 Alert Trigger
Array [10]
Select the event that triggers the user-defined action and
message.
Option:
[0] False
*
[1] True
[18] Reversing
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] Logic Controller Time-out 0
[31] Logic Controller Time-out 1
[32] Logic Controller Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] Logic Controller Time-out 3
[71] Logic Controller Time-out 4
[72] Logic Controller Time-out 5
[73] Logic Controller Time-out 6
[74] Logic Controller Time-out 7
[90] ECB Drive Mode
[91] ECB Bypass Mode
DET-620D
AF-600 FP™ Programming Guide
LC-91 Alert Action
Array [10]
Select the action that the frequency converter performs when
the event defined in parameter LC-90 Alert Trigger occurs.
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
Function:
[11]
[12]
[13]
[14]
LC-92 Alert Text
Array [10]
Range:
0 [0 - 20] Enter the text that the frequency converter shows
*
LC-97 Alert Alarm Word
Range:
0 [0 - 4294967295] Shows the alarm word of a user-defined
*
LC-98 Alert Warning Word
Range:
0 [0 - 4294967295] Shows the warning word of a user-
*
LC-99 Alert Status Word
Range:
0 [0 - 4294967295] Shows the status word of a user-defined
*
03/2016 All rights reserved.
Info
Warning
Freeze output
Freeze output & warn
Stop
Stop & warning
Jogging
Jogging & warning
Max speed
Max speed & warn
Stop and trip
Stop and trip w manual
reset
Trip
Trip w manual reset
Trip Lock
Function:
in the display when the event defined in
parameter 13-90 Alert Trigger occurs.
Function:
alarm in hex code.
Function:
defined alarm in hex code.
Function:
alarm in hex code.
Function:
