O-## Options/Comms - GE Ecomagination AF-600 FP Programming Manual

Parameter Lists
Par. No. # Parameter description
SP-42 Energy Savings Min. Frequency
SP-43 Motor Cosphi
SP-5#
SP-50 RFI Filter
SP-51 DC Link Compensation
SP-53 Fan Monitor
SP-54 AHF Cap Reconnect Delay
SP-55 Output Filter
5
5
SP-59 Actual Number of Inverter Units
SP-6#
SP-60 Function at Over Temperature
SP-61 Function at Drive Overload
SP-62 Drive Overload Derate Current

5.1.10 O-## Options/Comms

Par. No. # Parameter description
O-0#
O-01 Control Site
O-02 Control Word Source
O-03 Control Word Timeout Time
O-04 Control Word Timeout Function
O-05 End-of-Timeout Function
O-06 Reset Control Word Timeout
O-07 Diagnosis Trigger
O-08 Readout Filtering
O-09 Communication Charset
O-1#
O-10 Control Word Profile
O-13 Configurable Status Word STW
O-16 Store Data Values
O-19 Product Code
O-3#
O-30 Protocol
O-31 Address
O-32 Drive Port Baud Rate
O-33 Drive Port Parity
O-34 Estimated cycle time
O-35 Minimum Response Delay
O-36 Maximum Response Delay
O-37 Maximum Inter-Char Delay
O-4#
O-40 Telegram Selection
O-42 PCD Write Configuration
O-43 PCD Read Configuration
O-5#
O-50 Coasting Select
O-52 DC Brake Select
O-53 Start Select
218
Default value
ExpressionLimit
ExpressionLimit
[1] On
ExpressionLimit
[1] Warning
25 s
[0] No Filter
ExpressionLimit
[0] Trip
[0] Trip
95 %
Default value
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] Off
[1] Resume set-up
[0] Do not reset
[0] Disable
ExpressionLimit
[1] ANSI X3.4
[0] Drive Profile
[1] Profile Default
[0] Off
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
0 ms
ExpressionLimit
ExpressionLimit
ExpressionLimit
[1] Standard telegram 1
ExpressionLimit
ExpressionLimit
[3] Logic OR
ExpressionLimit
[3] Logic OR
