Parameter Description

3.12 PB-## PROFIdrive

The parameters in this group are common for Profibus and
PROFInet RT.
PB-00 Setpoint
3 3
Range:
0 [0 - 65535]
*
PB-07 Actual Value
Range:
0 [0 - 65535]
*
PB-15 PCD Write Configuration
Option:
[0] None
*
[7] Accel Time 1
[8] Decel Time 1
[15] Motor Speed High Limit [Hz]
[16] Motor Speed Low Limit [Hz]
[17] Motor Speed High Limit [RPM]
[18] Motor Speed Low Limit [RPM]
[40] Torque Limiter (Driving)
[41] Torque Limiter (Braking)
[52] Minimum Reference
[53] Maximum Reference
[110] Accel Time 2
[111] Decel Time 2
[163] Term. 29 High Ref./Feedb. Value
[168] Term. 33 High Ref./Feedb. Value
[190] Digital & Relay Bus Control
[193] Pulse Out #27 Bus Control
[195] Pulse Out #29 Bus Control
[197] Pulse Out #X30/6 Bus Control
[222] Jog Accel/Decel Time
[223] Quick Stop Decel Time
[615] Terminal 53 High Ref./Feedb. Value
[625] Terminal 54 High Ref./Feedb. Value
[653] Terminal 42 Output Bus Control
[663] Terminal X30/8 Output Bus Control
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[894] Bus Feedback 1
[895] Bus Feedback 2
[896] Bus Feedback 3
[1280] Fieldbus CTW 1
[1282] Fieldbus REF 1
[1285] Drive Port CTW 1
[1286] Drive Port REF 1
98
Function:
Function:
Function:
[0]
[515]
[894]
[895]
[896]
[1200] Control Word
[1201] Reference [Unit]
[1202] Reference [%]
[1203] Status Word
[1205] Main Actual Value [%]
[1209] Custom Readout
[1210] Power [kW]
[1211] Power [hp]
[1212] Torque [Nm]
[1213] Frequency
[1214] Motor current
[1215] Frequency [%]
[1217] Speed [RPM]
[1218] Motor Thermal
[1222] Torque [%]
[1224] Calibrated Stator Resistance
[1230] DC Link Voltage
[1232] Brake Energy /s
[1233] Brake Energy Average
[1234] Heatsink Temp.
[1235] Drive Thermal
[1238] Logic Controller State
[1239] Control Card Temp.
[1250] External Reference
[1252] Feedback[Unit]
[1253] Digi Pot Reference
[1254] Feedback 1 [Unit]
[1255] Feedback 2 [Unit]
[1256] Feedback 3 [Unit]
[1260] Digital Input
[1261] Terminal 53 Switch Setting
[1262] Analog Input 53
[1263] Terminal 54 Switch Setting
[1264] Analog Input 54
[1265] Analog Output 42 [mA]
[1266] Digital Output [bin]
03/2016 All rights reserved.
PB-16 PCD Read Configuration
Option:
None
*
Readout: Actual Set-up
Bus Feedback 1
Bus Feedback 2
Bus Feedback 3
Function:
Select the parameters to be
assigned to PCD 3 to 10 of
the messages. The number
of available PCDs depends
on the telegram type. PCDs
3 to 10 contain the actual
data values of the selected
parameters. For standard
Profibus message, see
parameter PB-22 Telegram
Selection.
