Parameter Description
AN-31 Terminal X30/11 High Voltage
Range:
10 V [par. AN-30 -
*
10 V]
3 3
AN-34 Term. X30/11 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999]
AN-35 Term. X30/11 High Ref./Feedb. Value
Range:
100 [-999999.999 -
*
999999.999]
AN-36 Term. X30/11 Filter Time Constant
Range:
0.001 s [0.001 - 10
*
s]
AN-37 Term. X30/11 Live Zero
Option:
[0] Disabled
[1] Enabled
*
3.7.6 AN-4# Analog Input 4 OPCGPIO
General Purpose I/O
Parameter group for configuring the scale and limits for
analog input 4 (X30/12) placed on General Purpose I/O
OPCGPIO General Purpose I/O.
72
Function:
Sets the analog input scaling value to
correspond to the high reference feedback
value (set in parameter AN-35 Term. X30/11
High Ref./Feedb. Value).
Function:
Sets the analog input scaling value to
correspond to the low voltage value (set
in parameter AN-30 Terminal X30/11 Low
Voltage).
Function:
Sets the analog input scaling value to
correspond to the high-voltage value
(set in parameter AN-31 Terminal X30/11
High Voltage).
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Enter the filter time constant. This
constant is a first-order digital low-pass
filter time for suppressing electrical noise
in terminal X30/11. A high value improves
dampening, but also increases the delay
through the filter.
Function:
This parameter makes it possible to disable the
live zero-monitoring. For example, to be used if
the analog outputs are used in a decentral I/O
system (when an analog output does not fulfil
any control function, but feeds a data storage
device).
AN-40 Terminal X30/12 Low Voltage
Range:
0.07 V [0 - par.
*
AN-41 V]
AN-41 Terminal X30/12 High Voltage
Range:
10 V [par. AN-40 -
*
10 V]
AN-44 Term. X30/12 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999]
AN-45 Term. X30/12 High Ref./Feedb. Value
Range:
100 [-999999.999 -
*
999999.999]
AN-46 Term. X30/12 Filter Time Constant
Range:
0.001 s [0.001 - 10
*
s]
AN-47 Term. X30/12 Live Zero
Option:
[0] Disabled
[1] Enabled
*
03/2016 All rights reserved.
Function:
Sets the analog input scaling value to
correspond to the low reference feedback
value set in parameter AN-44 Term. X30/12
Low Ref./Feedb. Value.
Function:
Sets the analog input scaling value to
correspond to the high reference feedback
value set in parameter AN-45 Term. X30/12
High Ref./Feedb. Value.
Function:
Sets the analog output scaling value to
correspond to the low voltage value set
in parameter AN-40 Terminal X30/12 Low
Voltage.
Function:
Sets the analog input scaling value to
correspond to the high-voltage value
set in parameter AN-41 Terminal X30/12
High Voltage.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Enter the filter time constant. This
constant is a first-order digital low-pass
filter time for suppressing electrical noise
in terminal X30/12. A high value improves
dampening, but also increases the delay
through the filter.
Function:
This parameter makes it possible to disable the
live zero-monitoring. For example, to be used if
the analog outputs are used in a decentral I/O
system (when an analog output does not fulfil
any control function, but feeds a data storage
device).
