GE Ecomagination AF-600 FP Programming Manual page 141

Parameter Description
FB-02 Fire Mode Unit
Option:
[31] kg/min
[32] kg/h
[33] t/min
3 3
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft3/s
[126] ft3/min
[127] ft3/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in2
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
FB-03 Fire Mode Min Reference
Range:
0 [-999999.999
FireMo- - par. FB-04
deUnit FireModeUnit]
*
140
Function:
Function:
Minimum value for the reference/
setpoint (limiting the sum of value in
parameter FB-05 Fire Mode Preset
Reference and value of signal on input
selected in parameter FB-06 Fire Mode
Reference Source).
If running in open loop when fire
mode is active, the unit is selected by
the setting of parameter K-02 Motor
Speed Unit. For closed loop, select the
unit in parameter FB-02 Fire Mode Unit.
FB-04 Fire Mode Max Reference
Range:
50.000
FireMo- 999999.999
deUnit FireModeUnit]
*
FB-05 Fire Mode Preset Reference
Range:
0 % [-100 -
*
100 %]
FB-06 Fire Mode Reference Source
Option:
[0] No function
*
[1] Analog Input 53
[2] Analog Input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital Potentiometer
[21] Analog input X30/11 (OPCGPIO)
[22] Analog input X30/12 (OPCGPIO)
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
03/2016 All rights reserved.
Function:
[par. FB-03 - Maximum value for the reference/
setpoint (limiting the sum of value in
parameter FB-05 Fire Mode Preset
Reference and value of signal on input
selected in parameter FB-06 Fire Mode
Reference Source).
If running in open loop when fire
mode is active, the unit is selected by
the setting parameter K-02 Motor Speed
Unit. For closed loop, select the unit in
parameter FB-02 Fire Mode Unit.
Function:
Enter the required preset reference/set point as
a percentage of the Fire Mode Max Reference
set in parameter FB-04 Fire Mode Max Reference.
The set value is added to the value represented
by the signal on the analog input selected in
parameter FB-06 Fire Mode Reference Source.
Function:
Select the external reference input to
be used for the fire mode. This signal
is added to the value set in
parameter FB-06 Fire Mode Reference
Source.
(OPCAIO)
(OPCAIO)
(OPCAIO)
DET-620D
