Parameter Description
3.3.3 E-5# I/O Mode / Add On I/O
E-51 Terminal 27 Mode
Option:
Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
[0]
Input
Defines terminal 27 as a digital input.
*
[1]
Output Defines terminal 27 as a digital output.
E-52 Terminal 29 Mode
Option:
Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
[0]
Input
Defines terminal 29 as a digital input.
*
[1]
Output Defines terminal 29 as a digital output.
E-53 Terminal X30/2 Digital Input
This parameter is active when the OPCGPIO General Purpose I/O
Option Module is installed in the frequency converter.
It has the same options and functions as parameter group E-0#
except for Pulse input [32].
E-54 Terminal X30/3 Digital Input
This parameter is active when the OPCRLY General Purpose I/O
Option Module is installed in the frequency converter.
It has the same options and functions as parameter group E-0#
except for Pulse input [32].
E-55 Terminal X30/4 Digital Input
This parameter is active when the General Purpose I/O Option
Module is installed in the frequency converter.
It has the same options and functions as parameter group E-0#
except for Pulse input [32].
E-56 Term X30/6 Digi Out (OPCGPIO)
This parameter is active when the General Purpose I/O Option
Module is mounted in the frequency converter.
Option:
E-57 Term X30/7 Digi Out (OPCGPIO)
This parameter is active when the General Purpose I/O Option
Module is mounted in the frequency converter.
Option:
DET-620D
AF-600 FP™ Programming Guide
Function:
Same options and functions
as parameter group E-2#.
Function:
Same options and functions
as parameter group E-2#.
03/2016 All rights reserved.
3.3.4 E-6# Pulse Input
E-60 Term. 29 Low Frequency
Range:
Function:
100
[0 - 110000
Enter the low frequency limit
Hz
Hz]
corresponding to the low motor shaft
*
speed (that is low reference value) in
parameter E-62 Term. 29 Low Ref./Feedb.
Value. Refer to in this section.
E-61 Term. 29 High Frequency
Range:
Function:
100 Hz
[0 - 110000
Enter the high frequency limit
*
Hz]
corresponding to the high motor shaft
speed (that is high reference value) in
parameter E-63 Term. 29 High Ref./Feedb.
Value.
E-62 Term. 29 Low Ref./Feedb. Value
Range:
Function:
0
[-999999.999 -
Enter the low reference value limit for the
*
999999.999]
motor shaft speed [RPM]. This is also the
lowest feedback value, see also
parameter E-67 Term. 33 Low Ref./Feedb.
Value.
E-63 Term. 29 High Ref./Feedb. Value
Range:
Function:
100
[-999999.999 -
Enter the high reference value [RPM]
*
999999.999]
for the motor shaft speed and the high
feedback value, see also
parameter E-68 Term. 33 High Ref./Feedb.
Value.
E-64 Pulse Filter Time Constant #29
Range:
Function:
NOTICE
100
[1 -
ms
1000 ms]
*
This parameter cannot be adjusted
while the motor is running.
Enter the pulse filter time constant. The
pulse filter dampens oscillations of the
feedback signal, which is an advantage if
there is a lot of noise in the system. A high
time constant value results in better
dampening, but also increases the time
delay through the filter.
3
3
49
