GE Ecomagination AF-600 FP Programming Manual page 111

Parameter Description
ID-10 Trending Source
Array [4]
Option:
[1233] Brake Energy Average
[1234] Heatsink Temp.
3 3
[1235] Drive Thermal
[1250] External Reference
[1252] Feedback[Unit]
[1254] Feedback 1 [Unit]
[1255] Feedback 2 [Unit]
[1256] Feedback 3 [Unit]
[1259] Adjusted Setpoint
[1260] Digital Input
[1262] Analog Input 53
[1264] Analog Input 54
[1265] Analog Output 42 [mA]
[1266] Digital Output [bin]
[1275] Analog In X30/11
[1276] Analog In X30/12
[1277] Analog Out X30/8 [mA]
[1290] Alarm Word
[1291] Alarm Word 2
[1292] Warning Word
[1293] Warning Word 2
[1294] Ext. Status Word
[1295] Ext. Status Word 2
[1330] Analog Input X42/1
[1331] Analog Input X42/3
[1332] Analog Input X42/5
[1333] Analog Out X42/7 [V]
[1334] Analog Out X42/9 [V]
[1335] Analog Out X42/11 [V]
[2110] Bypass Status Word
[2497] Alert Alarm Word
[2498] Alert Warning Word
[2499] Alert Status Word
ID-11 Trending Interval
Array [4]
Range:
0.000 [0.000 - 0.000] Enter the interval in ms between each
*
ID-12 Trigger Event
Option:
110
Function:
Function:
sampling of the variables to be logged.
Function:
Selects the trigger event. When
the trigger event occurs, a
window is applied to freeze the
log. The log then retains a
specified percentage of samples
before the occurrence of the
trigger event
(parameter ID-14 Samples Before
Trigger).
03/2016 All rights reserved.
ID-12 Trigger Event
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Line voltage out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
ID-13 Trending Mode
Option: Function:
[0] Trend Select [0] Log always for continuous logging.
*
always
[1] Trend once Select [1] Log once on trigger to conditionally
on trigger start and stop logging using
parameter ID-12 Trigger Event and
parameter ID-14 Samples Before Trigger.
Function:
