GE Ecomagination AF-600 FP Programming Manual page 97

Parameter Description
DN-13 Warning Parameter
Range:
0 [0 - 65535] View a DeviceNet-specific warning word. One
*
3 3
Bit Description
0 Bus not active.
1 Explicit connection timeout.
2 I/O connection.
3 Retry limit reached.
4 Actual is not updated.
5 CAN Network off.
6 I/O send error.
7 Restore error.
8 No bus supply.
9 Bus off.
10 Error passive.
11 Error warning.
12 Duplicate MAC ID error.
13 RX queue overrun.
14 TX queue overrun.
15 CAN overrun.
Table 3.13 Warning Bits
DN-14 Net Reference
Read only from keypad.
Option: Function:
Select the reference source in instances 21/71 and
20/70.
[0] Off Enables reference via analog/digital inputs.
*
[1] On Enables reference via the network.
DN-15 Net Control
Read only from keypad.
Option: Function:
Select the control source in instances 21/71 and 20/70.
[0] Off Enables control via analog/digital inputs.
*
[1] On Enable control via the network.
DN-18 internal_process_data_config_write
Range:
0
*
DN-19 internal_process_data_config_read
Range:
0
*
96
Function:
bit is assigned to every warning.
Function:
[0 - 9999]
Function:
[0 - 9999]
3.11.3 DN-2# COS Filters
DN-20 COS Filter 1
Range:
0 [0 - 65535] Enter the value for COS filter 1 to set up the
*
DN-21 COS Filter 2
Range:
0 [0 - 65535] Enter the value for COS filter 2 to set up the
*
DN-22 COS Filter 3
Range:
0 [0 - 65535] Enter the value for COS filter 3 to set up the
*
DN-23 COS Filter 4
Range:
0 [0 - 65535] Enter the value for COS filter 4 to set up the
*
3.11.4 DN-3# Parameter Access
Parameter group providing access to indexed parameters
and defining programming set-up.
DN-30 Array Index
Range:
0 [0 - 255] View array parameters. This parameter is valid only
*
03/2016 All rights reserved.
Function:
filter mask for the status word. When operating
in COS (change-of-state), this function filters out
bits in the status word that should not be sent
if they change.
Function:
filter mask for the Main Actual Value. When
operating in COS, this function filters out bits in
the main actual value that should not be sent if
they change.
Function:
filter mask for PCD 3. When operating in COS,
this function filters out bits in PCD 3 that
should not be sent if they change.
Function:
filter mask for PCD 4. When operating in COS,
this function filters out bits in PCD 4 that
should not be sent if they change.
Function:
when a DeviceNet MCA 104 is installed.
