Parameter Description
T-01 ON Action
Array [10]
Option:
[41] Set digital out D high
[42] Set digital out E high
3 3
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[62] Counter A (up)
[63] Counter A (down)
[64] Counter B (up)
[65] Counter B (down)
[80] Sleep Mode
T-02 OFF Time
Array [10]
Range:
0 [0 - 0] Sets the OFF time for the timed action.
*
NOTICE
The frequency converter has no back-up of
the clock function and the set date/time is
reset to default (2000-01-01 00:00) after a
power-down unless the Analog I/O option
module (OPCAIO) with Battery Back Up of
the Real Time Clock is installed. In
parameter K-79 Clock Fault, it is possible to
programme a warning if the clock has not
been set properly, for example after a
power-down.
T-03 OFF Action
Array [10]
Option:
[1] No action
*
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select Accel/Decel 1
[19] Select Accel/Decel 2
[22] Run
144
Function:
Function:
Function:
Select the action during OFF time.
See parameter LC-52 Logic Controller
Action for descriptions of the
options.
T-03 OFF Action
Array [10]
Option:
[23] Run reverse
[24] Stop
[26] DC Brake
[27] Coast
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[36] Set digital out E low
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[62] Counter A (up)
[63] Counter A (down)
[64] Counter B (up)
[65] Counter B (down)
[80] Sleep Mode
T-04 Occurrence
Array [10]
Option:
[0] All days
*
[1] Working days
[2] Non-working
days
[3] Monday
[4] Tuesday
[5] Wednesday
[6] Thursday
[7] Friday
[8] Saturday
[9] Sunday
03/2016 All rights reserved.
Function:
Function:
Select which day(s) the timed action
applies to. Specify working/non-working
days in:
•
Parameter K-81 Working Days.
•
Parameter K-82 Additional Working
Days.
•
Parameter K-83 Additional Non-
Working Days.
