Parameter Description
O-33 Drive Port Parity
Option: Function:
[0] Even Parity, 1
*
Stop Bit
[1] Odd Parity, 1
Stop Bit
[2] No Parity, 1 Stop
Bit
[3] No Parity, 2 Stop
Bits
O-34 Estimated cycle time
Range: Function:
0 ms [0 - In noisy environments, the interface may
*
1000000 ms] be blocked due to overload or bad frames.
This parameter specifies the time between
2 consecutive frames on the network. If the
interface does not detect valid frames in
that time, it flushes the receive buffer.
O-35 Minimum Response Delay
Range: Function:
10 ms [5 - 10000 Specify the minimum delay time
*
ms] between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
O-36 Maximum Response Delay
Range: Function:
10001 ms [11 - 10001 Specify the maximum permissible
*
ms] delay time between transmitting a
request and receiving a response.
Exceeding this delay time causes
control word timeout.
O-37 Maximum Inter-Char Delay
Range: Function:
25.00 ms [0.00 - 35.00 Specify the maximum permissible
*
ms] time interval between receipt of 2
bytes. This parameter activates
timeout if transmission is interrupted.
3.9.4 O-4# Drive MC protocol set
O-40 Telegram Selection
Option: Function:
Enables use of freely configurable
messages or standard messages for
the Drive port.
[1] Standard telegram 1
*
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
DET-620D
AF-600 FP™ Programming Guide
O-40 Telegram Selection
Option:
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
O-42 PCD Write Configuration
Option:
[0]
*
[7]
[8]
[15]
[16]
[17]
[18]
[40]
[41]
[52]
[53]
[110]
[111]
[163]
[168]
[190]
[193]
[195]
[197]
[222]
[223]
[615]
[625]
[653]
[663]
[890]
[891]
[894]
[895]
[896]
[1280] Fieldbus CTW 1
[1282] Fieldbus REF 1
[1285] Drive Port CTW 1
[1286] Drive Port REF 1
03/2016 All rights reserved.
Function:
None
Accel Time 1
Decel Time 1
Motor Speed High Limit [Hz]
Motor Speed Low Limit [Hz]
Motor Speed High Limit [RPM]
Motor Speed Low Limit [RPM]
Torque Limiter (Driving)
Torque Limiter (Braking)
Minimum Reference
Maximum Reference
Accel Time 2
Decel Time 2
Term. 29 High Ref./Feedb. Value
Term. 33 High Ref./Feedb. Value
Digital & Relay Bus Control
Pulse Out #27 Bus Control
Pulse Out #29 Bus Control
Pulse Out #X30/6 Bus Control
Jog Accel/Decel Time
Quick Stop Decel Time
Terminal 53 High Ref./Feedb. Value
Terminal 54 High Ref./Feedb. Value
Terminal 42 Output Bus Control
Terminal X30/8 Output Bus Control
Bus Jog 1 Speed
Bus Jog 2 Speed
Bus Feedback 1
Bus Feedback 2
Bus Feedback 3
3
Function:
Select the parameters
to be assigned to
PCD's messages. The
number of available
PCDs depends on the
message type. The
values in PCD's will
then be written to
the selected
parameters as data
values.
