Parameter Description
AN-55 Terminal 42 Output Filter
Option: Function:
The following readout parameters from selection in
parameter AN-50 Terminal 42 Output have a filter
selected when parameter AN-55 Terminal 42 Output
Filter is on:
Selection
Motor current (0–I
max
Torque limit (0–T )
lim
Rated torque (0–T
nom
Power (0–P )
nom
Speed (0–Speed )
max
Table 3.11 Readout Parameters
[0] Off Filter off.
*
[1] On Filter on.
3.7.8 AN-6# Analog Output 2 OPCGPIO
General Purpose I/O
Analog outputs are current outputs: 0/4–20 mA. Common
terminal (terminal X30/8) is the same terminal and
electrical potential for analog common connection.
Resolution on analog output is 12 bit.
AN-60 Terminal X30/8 Output
Same options and functions as parameter AN-50 Terminal 42
Output.
AN-61 Terminal X30/8 Min. Scale
Range: Function:
0 % [0 - Scales the minimum output of the selected analog
*
200 %] signal on terminal X30/8. Scale the minimum value
as a percentage of the maximum signal value, that
is 0 mA (or 0 Hz) is required at 25% of the
maximum output value and 25% is programmed.
The value can never exceed the corresponding
setting in parameter AN-62 Terminal X30/8 Max.
Scale if the value is below 100%.
This parameter is active when General Purpose I/O
OPCGPIO General Purpose I/O is mounted in the
frequency converter.
AN-62 Terminal X30/8 Max. Scale
Range: Function:
100 [0 - Scales the maximum output of the selected
% 200 % analog signal on terminal X30/8. Scale the value
*
] to the required maximum value of the current
signal output. Scale the output to give a lower
current than 20 mA at full scale, or 20 mA at an
output below 100% of the maximum signal value.
If 20 mA is the required output current at a value
between 0–100% of the full-scale output,
program the percentage value in the parameter,
DET-620D
AF-600 FP™ Programming Guide
0–20 mA 4–20 mA
) [103] [133]
[104] [134]
) [105] [135]
[106] [136]
[107] [137]
03/2016 All rights reserved.
AN-62 Terminal X30/8 Max. Scale
Range: Function:
that is 50%=20 mA. If a current 4–20 mA is
required at maximum output (100%), calculate
the percentage value as follows:
20 mA/desired maximum current × 100 %
20 mA
i . e . 10 mA: × 100 % = 200 %
10 mA
AN-63 Terminal X30/8 Output Bus Control
Range: Function:
0 % [0 - 100 %] Contains the value to apply to the output
*
terminal when it is configured as bus-
controlled.
AN-64 Terminal X30/8 Output Timeout Preset
Range: Function:
0 % [0 - 100 %] Contains the value to apply to the output
*
terminal, when it is configured as bus-
controlled timeout and timeout is detected.
3 3
