Parameter Description

3.6 H-## High Perf Parameters

3.6.1 H-0# High Perf Operations
H-01 Option Detection
3 3
Option:
[0] Protect
*
Option
Config.
[1] Enable
Option
Change
H-03 Restore Factory Settings
Option:
[0] Normal
operation
*
[2] Restore
Factory
Settings
H-04 Auto-Reset (Times)
Option:
[0] Manual reset
[1] Automatic reset x 1
62
Function:
Freezes the current settings and prevents
unwanted changes when missing or
defective options are detected.
Changes frequency converter settings and is
used when modifying the system configu-
ration. This parameter setting returns to [0]
Protect Option Config. after an option
change.
Function:
Use this parameter to specify normal operation,
to perform tests, or to restore all parameters
except:
•
Parameter ID-03 Power Up's.
•
Parameter ID-04 Over Temp's.
•
Parameter ID-05 Over Volt's.
This function is active only when the power is
cycled (power off/power on) to the frequency
converter.
Normal operation of the frequency converter
with the motor in the selected application.
[2] Restore Factory Settings Resets all parameter
values to default settings, except for:
•
Parameter ID-03 Power Up's.
•
Parameter ID-04 Over Temp's.
•
Parameter ID-05 Over Volt's.
The frequency converter resets during the next
power-up.
Parameter H-03 Restore Factory Settings also
reverts to the default setting [0] Normal
operation.
Function:
Select the reset function after
tripping. Once reset, the frequency
converter can be restarted.
Select [0] Manual reset, to perform a
reset via [RESET] or via the digital
inputs.
Select Automatic reset x 1...x20 [1]-
[12] to perform between one and
twenty automatic resets after
tripping.
H-04 Auto-Reset (Times)
Option:
[2] Automatic reset x 2
[3] Automatic reset x 3
[4] Automatic reset x 4
[5] Automatic reset x 5
[6] Automatic reset x 6
[7] Automatic reset x 7
[8] Automatic reset x 8
[9] Automatic reset x 9
[10] Automatic reset x 10
[11] Automatic reset x 15
[12] Automatic reset x 20
[13] Infinite auto reset
*
NOTICE
The motor may start without warning. If the specified
number of AUTOMATIC RESETs is reached within 10
minutes, the frequency converter enters Manual reset [0]
mode. After the Manual reset is performed, the setting
of parameter H-04 Auto-Reset (Times) reverts to the
original selection. If the number of automatic resets is
not reached within 10 minutes, or when a Manual reset
is performed, the internal AUTOMATIC RESET counter
returns to zero.
H-05 Auto-Reset (Reset Interval)
Range:
10 s [0 - 600
*
s]
H-06 Fan Operation
Option:
[0] Auto
*
[1] On 50%
[2] On 75%
[3] On 100%
[4] Auto (Low
temp env.)
03/2016 All rights reserved.
Function:
Select [13] Infinite Automatic Reset
for continuous resetting after
tripping.
Function:
Enter the time interval from trip to start of the
automatic reset function. This parameter is
active when parameter H-04 Auto-Reset (Times)
is set to [1]–[13] Automatic reset.
Function:
Select the minimum speed of the main fan.
Select [0] Auto to run the fan only when the
internal temperature of the frequency
converter is in the range 35 °C (95 °F) to
approximately 55 °C (131 °F). The fan runs at
low speed at 35 °C (95 °F) and at full speed
at approximately 55 °C (131 °F).
