Parameter Lists

5 Parameter Lists

5.1 Parameter Options

5.1.1 Main Menu Structure
Parameters for the frequency converter are grouped into
various parameter groups for easy selection of the correct
parameters for optimised operation of the frequency
converter.
5
5
To programme most AF-600 FP applications, press [Quick
Menu] and select the parameters under Quick Set-up.
Descriptions and default settings of parameters may be
found in chapter 5.1 Parameter Options.
K-## Keypad Set-up
F-## Fundamental Parameters
E-## Digital In/Outs
C-## Frequency Control Functions
P-## Motor Data
H-## High Perf Parameters
AN-## Analog In/Out
SP-## Special Functions
O-## Options/Comms
AO-## Analog I/O Options
PB-## PROFIdrive
EN-## Ethernet
LN-## LonWorks
BN-## BACnet
DN-## DeviceNet
ID-## Drive Information
DR-## Data Readouts
LG-## Logs & I/O Opt. Status
AP-## HVAC Appl. Param.
FB-## Fire/Bypass Operation
T-## Timed Functions
CL-## PID Closed Loop
XC-## Ext. PID Closed Loop
PC-## Pump Controller
LC-## Logic Controller
B-## Braking Functions
