Parameter Description
[130] Pump 1
Interlock
[131] Pump 2
Interlock
[132] Pump 3
Interlock
E-00 Digital I/O Mode
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Digital inputs and programmed digital
outputs are pre-programmable for operation
either in PNP or NPN systems.
[0] PNP - Active Action on positive directional pulses (0). PNP
*
at 24V systems are pulled down to GND.
[1] NPN - Active Action on negative directional pulses (1).
at 0V NPN systems are pulled up to +24 V,
internally in the frequency converter.
E-01 Terminal 18 Digital Input
Option: Function:
Same options and functions as E-0#, except for Pulse
input.
E-02 Terminal 19 Digital Input
Option: Function:
Same options and functions as E-0#, except for Pulse
input.
E-03 Terminal 27 Digital Input
Option: Function:
Same options and functions as parameter group E-0#,
except for Pulse input.
E-04 Terminal 29 Digital Input
Option: Function:
Same options and functions as parameter group E-0#,
except for Pulse input.
E-05 Terminal 32 Digital Input
Option: Function:
Same options and functions as parameter group E-0#.
E-06 Terminal 33 Digital Input
Option: Function:
Same options and functions as parameter group. E-0#.
DET-620D
AF-600 FP™ Programming Guide
3.3.1 E-1# Additional Accel Decel Ramps
Choosing ramp parameters.
E-10 Accel Time 2
Range:
10.00
s
*
E-11 Decel Time 2
Range:
20.00
s
*
3.3.2 E-2# Digital Outputs
[0] No operation
*
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem
ctrl
[4] Standby / no
warning
[5] Running
[6] Running / no
warning
[8] Run on ref/no
warn
[9] Alarm
[10] Alarm or
warning
[11] At torque
limit
[12] Out of current
range
03/2016 All rights reserved.
Function:
[1.00 - Enter the accel time, that is the acceleration
3600 s] time from 0 RPM–parameter P-06 Base Speed.
Select a accel time such that the output
current does not exceed the current limit in
parameter F-43 Current Limit during ramping.
See decel time in parameter E-11 Decel Time 2.
tacc × nnom par . P − 06
par . E − 10 =
ref rpm
Function:
[1.00 Enter the decel time, that is the deceleration
- 3600 time from parameter P-06 Base Speed–0 RPM.
s] Select a decel time such that no overvoltage
arises in the inverter due to regenerative
operation of the motor, and such that the
generated current does not exceed the current
limit set in parameter F-43 Current Limit. See
accel time in parameter E-10 Accel Time 2.
tdec × nnom par . P − 06
par . E − 11 =
ref rpm
Default for all digital outputs and relay
outputs.
The control board receives supply voltage.
The control board receives supply voltage.
The frequency converter is ready for
operation and applies a supply signal on
the control board.
Ready for operation. No start or stop
command is been given (start/disable).
There are no warnings.
Motor is running.
Output speed is higher than the speed set
in parameter H-81 Min Speed for Function at
Stop [RPM]. The motor is running and there
are no warnings.
Motor runs at reference speed.
An alarm activates the output. There are
no warnings.
An alarm or a warning activates the
output.
The torque limit set in
parameter F-40 Torque Limiter (Driving) has
been exceeded.
The motor current is outside the range set
in parameter F-43 Current Limit.
