Parameter Description
PB-16 PCD Read Configuration
Option:
[1267] Freq. Input #29 [Hz]
[1268] Freq. Input #33 [Hz]
[1269] Pulse Output #27 [Hz]
[1270] Pulse Output #29 [Hz]
[1271] Relay Output [bin]
[1272] Counter A
[1273] Counter B
[1275] Analog In X30/11
[1276] Analog In X30/12
[1277] Analog Out X30/8 [mA]
[1284] Comm. Option STW
[1285] Drive Port CTW 1
[1290] Alarm Word
[1291] Alarm Word 2
[1292] Warning Word
[1293] Warning Word 2
[1294] Ext. Status Word
[1295] Ext. Status Word 2
[1296] Maintenance Word
[1330] Analog Input X42/1
[1331] Analog Input X42/3
[1332] Analog Input X42/5
[1333] Analog Out X42/7 [V]
[1334] Analog Out X42/9 [V]
[1335] Analog Out X42/11 [V]
[1500] Operating hours
[1501] Running Hours
[1502] kWh Counter
[2497] Alert Alarm Word
[2498] Alert Warning Word
[2499] Alert Status Word
PB-18 Node Address
Range: Function:
126 [0 - Enter the station address in this parameter or,
*
126] alternatively, in the hardware switch. To adjust the
station address in parameter PB-18 Node Address,
set the hardware switch to 126 or 127 (all
switches set to ON). Otherwise, this parameter
shows the actual setting of the switch.
PB-22 Telegram Selection
Option: Function:
Select a standard PROFIBUS telegram
configuration for the frequency
converter as an alternative to using
the freely configurable messages in
parameter PB-15 PCD Write Configu-
ration and parameter PB-16 PCD Read
Configuration.
[1] Standard telegram
1
DET-620D
AF-600 FP™ Programming Guide
Function:
03/2016 All rights reserved.
PB-22 Telegram Selection
Option: Function:
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
*
PB-23 Parameters for Signals
Array [1000]
Option: Function:
This parameter contains a list of signals available for
selection in parameter PB-15 PCD Write Configuration
and parameter PB-16 PCD Read Configuration.
PB-27 Parameter Edit
Option: Function:
Edit parameters via:
•
PROFIBUS.
•
The standard RS485 interface.
•
The keypad.
[0] Disabled Disables editing via PROFIBUS.
[1] Enabled Enables editing via PROFIBUS.
*
PB-28 Process Control
Option: Function:
Process control (setting of control word, speed
reference, and process data) is possible via either
PROFIBUS or standard Network, but not both
simultaneously. Local control is always possible via
the keypad. Control via process control is possible
via either terminals or Network depending on the
settings in parameter O-50 Coasting Select to
parameter O-56 Preset Reference Select.
[0] Disable Disables process control via PROFIBUS master
class 1 and enables process control via standard
Network or PROFIBUS master class 2.
[1] Enable Enables process control via PROFIBUS master class
cyclic 1 and disables process control via standard
*
master Network or PROFIBUS master class 2.
PB-44 Fault Message Counter
Range: Function:
0 [0 - Indicates the number of fault events presently
*
65535] stored in parameter PB-45 Fault Code. The buffer
capacity is maximum 8 error events. The buffer
and counter are set to 0 by reset or power-up.
