Parameter Description
K-30 Unit for Custom Readout
Option:
3 3
[0]
[1] %
*
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m3/s
[24] m3/min
[25] m3/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft3/s
[126] ft3/min
[127] ft3/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in2
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
30
Function:
[DR-09 Custom Readout] in parameter K-20 Display
Line 1.1 Small to parameter K-24 Display Line 3
Large.
K-31 Min Value of Custom Readout
Range:
0.00 Custom-
ReadoutUnit
0.00 Custom-
ReadoutUnit
K-32 Max Value of Custom Readout
Range:
100 Custom-
ReadoutUnit
K-37 Display Text 1
Range:
0 [0 -
*
25]
03/2016 All rights reserved.
Function:
[-999999.99 - This parameter allows selection
100.00 of the minimum value of the
*
CustomRea- custom-defined readout
doutUnit] (occurs at zero speed). It is
only possible to select a value
different from 0 when selecting
a linear unit in
parameter K-30 Unit for Custom
Readout. For quadratic and
cubic units the minimum value
is 0.
[-999999.99 -
100.00
*
CustomRea-
doutUnit]
Function:
[par. K-31 - This parameter sets the
999999.99 maximum value to be shown
*
CustomRea- when the speed of the motor
doutUnit] has reached the set value for
parameter F-17 Motor Speed
High Limit [RPM] or
parameter F-15 Motor Speed
High Limit [Hz] (depends on
setting in parameter K-02 Motor
Speed Unit).
Function:
In this parameter, it is possible to write an individual
text string to show in the keypad or to be read via
serial communication. To show the text permanently,
select [37] Display Text 1 in 1 of the following
parameters:
•
Parameter K-20 Display Line 1.1 Small.
•
Parameter K-21 Display Line 1.2 Small.
•
Parameter K-22 Display Line 1.3 Small.
•
Parameter K-23 Display Line 2 Large.
•
Parameter K-24 Display Line 3 Large.
•
Parameter K-37 Display Text 1.
Changing parameter EN-08 Host Name changes
parameter K-37 Display Text 1 - but not vice versa.
