Table 3-24. Vector Analog Pane Menu Structure
Selection
ANALOG STANDARD
POSITION
SETUP
Table 3-25. Vector SD-SDI Pane Menu Structure
Selection
SD STANDARD
SCALE SD TO
COMPOSITE
POSITION
SETUP
Table 3-26. Vector HD-SDI Pane Menu Structure
Selection
HD STANDARD
SCALE HD TO
COMPOSITE
POSITION
VECTOR SETUP

Standard

NOTE: This selection also is reflected in the Gamut display for the selected pane.
Standard is used to set the marks on the vector display. The marks on the vector help to
visualize the minimum/maximum value of a video signal. The position of the excursion
marks are 75% or 100% for analog, SD, and HD. Also, the HD standard can be
selected as 75% and 100% simultaneously.

Scaled to Composite (SD and HD only)

Also, with an HD or SD signal, the Scaled to Composite menu can be used to scale the
SD or HD vector to reflect a composite format.
70
General Operation
Selection Option
75%
100%
Use H POS and V POS knob. Press KNOB for center.
Press ENT
Selection Option
75%
100%
OFF
ON
Use H POS and V POS knob. Press KNOB for center.
Press ENT
Selection Option
75%
100%
75% + 100%
OFF
ON
Use H POS and V POS knob. Press KNOB for center.
Press ENT
