Analysis), and one TVM-VTM-SDI-H (SD/HD) input module. The package is
limited to SD/HD formats, but can be upgraded.
• TVM9140PKG-3GB: This TVM Series package includes the TVM-ASX
(console), TVM-40 (affords the ability for four source inputs simultaneously and
Data Analysis), and one TVM-VTM-3GB input module. There are no format
limitations on the VTM-9140 PKG-3GB.
• TVM9140PKG-A: This TVM Series package includes the TVM-ASX (console),
TVM-40 (affords the ability for four source inputs simultaneously and Data
Analysis) and TVM-VTM-ACV-2 dual composite analog input module. The
package is limited to Analog formats, but can be upgraded. (Data Analysis is active
when using a digital option board.)
• TVM9140PKG-EH: This TVM Series package includes the TVM-ASX (console),
TVM-40 (affords the ability for four source inputs simultaneously and Data
Analysis), and one TVM-VTM-EYE-H (SD/HD EYE) input module. The package
is limited to SD/HD formats, but can be upgraded.
• TVM9140PKG-EJ: This TVM Series package includes the TVM-ASX (console),
TVM-40 (affords the ability for four source inputs simultaneously and Data
Analysis), and one TVM-VTM-JEM (SD/HD EYE Advanced Jitter Analysis) input
module. The package is limited to SD/HD formats, but can be upgraded.
• TVM9140PKG-ES: This TVM Series package includes the TVM-ASX (console),
TVM-40 (affords the ability for four source inputs simultaneously and Data
Analysis), and one TVM-VTM-EYE-S (SD EYE) input module. The package is
limited to SD formats, but can be upgraded. (HD upgrade is TVM-VTM-S2H-F.)
• TVM9140PKG-SD: This TVM Series package includes the TVM-ASX (console),
TVM-40 (affords the ability for four source inputs simultaneously and Data
Analysis), and one TVM-VTM-SDI-S (SD) input module. The package is limited
to SD formats, but can be upgraded. (HD upgrade is TVM-VTM-S2H-F.)
