Videotek TVM9100PKG Installation And Operation Handbook page 248

TVM Options
Item
TVM-VTM-AAP
TVM-A3-OPT 2
TVM-A3- 4004
TVM-A3-OPT 3
TVM-A3-OPT 3TL
TVM-A3-OPT 5
TVM-A3-OPT 5TL
TVM-A3-OPT 3TO5
TVM-OPT V2A
RCU-1000
TVM-WRTY1
TVM-WRTY2
SSC-2
PTC-2
DRC-2A
224
Specifications
Specification
Software Feature Upgrade. Advanced Analysis Package that adds
data analyzer functions in quadrant or full-screen views to the
TVM-10. (Included in TVM-40.)
Advanced Audio Analysis Option. Bargraphs and CineSound
up to 8 audio channels. Includes 4 analog stereo inputs, 4 AES/EBU
shared input/output pairs and 16 channels of embedded audio.
Analog monitoring outputs of up to 8 channels simultaneously.
Audio Expansion module. Adds 4 AES/EBU input pairs. Only
available with A3-OPT 2.
Advanced Audio Analysis Option. Bargraphs and CineSound®. View
up to 8 audio channels. Includes 4 analog stereo inputs, 8 AES/EBU
inputs with 4 shared output and 16 channels of embedded audio.
Analog monitoring outputs of up to 8 channels simultaneously.
Advanced Audio Analysis Option with 5x oversampling for enhanced
True Peak detection. Bargraphs and CineSound®. View up to eight
audio channels. Includes four analog stereo inputs, eight AES/EBU
inputs with four-shared outputs and 16 channels of embedded audio.
Analog monitoring outputs of up to eight channels simultaneously.
Channel-mapping, loudness, meter labels, and peak value reporting
included. All AES inputs are sample rate converted to 48 kHz.
Full Dolby decoding. Advanced Audio Analysis Option. Bargraphs
and CineSound®. View up to 8 audio channels. Includes 4 analog
stereo inputs, 8 AES/EBU inputs with 4 shared output and 16
channels of embedded audio. Analog monitoring outputs of up to 8
channels simultaneously.
Advanced Audio Analysis Option with 5x oversampling for enhanced
True Peak detection and Dolby. Bargraphs and CineSound®. View
up to eight audio channels. Includes four analog stereo inputs, eight
AES/EBU inputs with four-shared outputs and 16 channels of
embedded audio. Analog monitoring outputs of up to eight channels
simultaneously. Channel-mapping, loudness, meter labels, and peak
value reporting included. All AES inputs are sample rate converted to
48 kHz. It also adds full Dolby decoding to the analog output. The
Dolby Output is selectable from any 1 of the 8 pairs of the assigned
input type (AES or Embedded). Further, selection of an AES or
embedded pair for the AUX meters is available in an eight-channel
display.
Adds Dolby decoding to existing TVM-A3-OPT 3 A-D and
TVM-A3-OPT 3-TL
Adds Lip Sync to the TVM-A3-OPT 3 or TVM-A3-OPT 5
Remote control panel for the TVM series, VTM series, instructions;
replicates all of the front panel controls; RS-422 connection, includes
50 ft (15 m) of cable with RJ-11 connectors; One RU in height
Full Extended Warranty Plan: Adds three years to the standard two-
year warranty, including a one-year extension on the LCD display
warranty
Adds three years to the standard two-year warranty
Single standard case
Portable case with folding stand
Double Rackmount Case
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
®
