Table 1-4. HD Formats

1080i
1080I/60
1080I/59.94
1080I/50
1080p
1080P/30
1080P/29.97
1080P/25
1080P/24
1080P/23.98
720p
720p/60
720p/59.94
720p/50
720p/30
720p/29.97
720p/24
720p/23.98
Segmented Frame
1080P/30sF
1080P/29.97sF
1080P/25sF
1080P/24sF
1080P/23.98sF
10
Introduction
10 bit
4:2:2
YCbCr
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation

Table 1-5. SD Formats

10 bit
4:2:2
YCbCr
525/59.94
X
625/50
X
Analog
Table 1-6.
Composite Formats
Supported
NTSC
X
PAL
X
