Appendix A ♦ Specifications
Specifications are subject to change without notice.
Video Input Specifications: 3G/HD-SDI/SD-SDI Option
Item
Digital inputs
Data rate
Connectors
Level
Input cable equalization
Return loss
Monitor output
Monitor output data rate
Monitor output connector
Monitor output level
Video Input Specifications: HD-SDI/SD-SDI Option
Item
Digital inputs
Data rate
Connectors
Level
Input EQ
Return loss
Monitor output
Specification
Two (2) dual standards inputs accepting Standard definition, SMPTE
259 MC formats or High definition SMPTE 292M, 372M, 424M,
425M-AB formats including: 525/59.94, 625/50, 1080i/60,
1080i/59.94, 1080i/50, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30,
1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98, 1080/30sF,
1080/29.97sF, 1080/25sF, 1080/24sF, 1080/23.98sF, 720p/60,
720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/24 Hz, 720p/23.98,
Format Standard Dual Link SMPTE 372M 4:4:4 (YC
270 MB/s, 1.485 Gb/s, 2.97 Gb/s, auto detect; also div by 1.001 rates
4 BNCs, active looping inputs
1 BNC monitor output
800 mV, nominal source amplitude
Up to 80 meters of Belen 1694A from 1.485 Gb/s to 2.97 Gb/s
Up to 100 meters of Belden 8281 at 1.485 Gb/s
Up to 250 meters of Belden 8281 at 270 Mb/S
≤ -15 dB 5 MHz to 1.485 GHz
≤ -10 dB 1.485 GHz to 2.97 Gb/s
Follows the selected digital input
270 Mb/s, 1.485 Gb/s and 2.97 GHz
BNC
800 mV, nominal
Specification
Two (2) dual standards inputs accepting Standard definition, SMPTE
259 MC formats or High definition SMPTE 292M, 372M, formats
including: 525/59.94, 625/50, 1080i/60, 1080i/59.94, 1080i/50,
1080p/30, 1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98,
1080/30sF, 1080/29.97sF, 1080/25sF, 1080/24sF, 1080/23.98sF,
720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/24 Hz,
720p/23.98, Format Standard Dual Link SMPTE 372M 4:4:4 (YC
10 bit
270 MB/s, 1.485 Gb/s auto detect
4 BNCs, Hi-Z passive looping
4 BNCs, active looping with option EYE-H
800 mV, nominal
Up to 100 meters of Belden 8281 at 1.485 Gb/s
Up to 250 meters of Belden 8281 at 270 Mb/S
≤ -25 dB 100 kHz to 270 MHz
≤ -15 dB 5 MHz to 1.485 GHz
Follows the selected digital input
