Table 3-6. Description of Waveform Display Diagram
Field
Field information
Identifier
3 Filter
4 Standard
5 Reference
6 Gain
7 Amplitude cursor readout
8 Time cursor readout
9 Line select information
10 WFM graticule
11 Scale
12 Zoom
Graticules are configured by selecting the Video Input Format along with the
appropriate Waveform Setup scale adjustment (Units, %, or Volts). The scales can also
change when ZOOM is pressed.
Figure 3-7 to Figure 3-9 illustrates some waveform graticules with the critical
amplitude limits for the video formats that can be displayed by the TVM. The critical
amplitude limits are indicated on the screen by special dashed lines.
NOTE: When in VAR mode for all waveform scales, the graticule scale and numeric identifiers
will not be shown. Only the graticule lines will be displayed.
General Operation
Nomenclature
•
Displayed as FLT, LP, CHR, BOW (Bowtie), R-Y
•
This can be selected in the COMPOSITE or
COMPONENT FILTER submenu of the WFM Pane
menu
Displays the Line Rate/Frame Rate [1080i/59.94]; this is
selected in the VIDEO FORMAT > VIDEO A though D
CONFIGURE menu
Displays the reference as INT, EXT (toggled by pressing
the EXT button)
Displays the selected gain; Gain ranges are 0.5 to 15.0
(change by pressing the STEP or VAR button)
Displays the amplitude cursor as AMP and the selected
numerical value followed by the unit or measure (mV, units,
or IRE)
Displays the time cursor as TIME and the selected
numerical value followed by the unit or measure (µs)
Line select is shown as Line number with the ODD or
EVEN field (odd or even field will only show for interlaced
Video Formats)
Shows the WFM RGB, YC
graticule is dependent upon the Video format, Zoom, and
scale selections
Indicates the major graticule indications for time
•
Displays Zoom when enabled
• Blank when Zoom is disabled
•
Press the ZOOM button to cycle through the ZOOM
modes
