Videotek TVM9100PKG Installation And Operation Handbook page 177

Table 4-9. Video Alarms, Analog Menu
Selection Selection Option
BURST LEVEL
LOWER
BURST/CHROMA ENABLE
PHASE
FIELD
LINE
POSITION
PHASE
RANGE
DURATION
H BLANKING OFF (Default)
WIDTH NTSC
Global Setup Menu Functions
Selection Option
THRESHOLD NTSC
THRESHOLD PAL
DURATION
ENABLE
THRESHOLD NTSC
THRESHOLD PAL
DURATION
OFF
ON
ODD (Default)
EVEN
1 TO 50 LINE(S) (25
LINES is Default)
0.0 TO 64.0 µs (49.5
microseconds is the
default)
0 TO 359.75
DEGREE(S) (283.5 is
Default)
5 TO 20 DEGREE(S)
(7.5 is Default)
0 TO 60 SECONDS (2
Seconds is Default)
-
NTSC µ SECONDS:
8 TO 16 µ SECONDS
(10.9 is Default)
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Selection Option
ON
NTSC IRE:
42 TO 50 IRE
(45 is Default)
•
PAL UNITS:
46 TO 51 UNITS
(46 UNITS is Default)
•
PAL mV:
321 TO 357 mV
(322 mV is Default)
0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default)
ON
NTSC IRE:
20 TO 38 IRE
(35 is Default)
•
PAL UNITS:
20 TO 42 UNITS
(36 UNITS is Default)
•
PAL mV:
143 TO 293 mV
(252 mV is Default)
0 TO 60 SECONDS (2
Seconds is Default)
-
-
-
-
-
-
-
-
-
-
-
